CUBE 2000
WORLD'S SMALLEST
HIGH POWER TV
TRANSMITTER KIT
Ramsey Electronics Model No.
Transmits perfect video - and you can hide it under a quarter!
Fully assembled, just add a camera and battery for a complete
hide-it-anywhere video transmitter! A few years ago, only the
CIA or the KGB had anything like this!
•
Great for transmitting from the baby's room throughout the house
•
Tiny enough with battery and CCD camera to hide into a pack of
cigarettes or even a pager !
•
Easy hook-up to any CCD video camera - Color or Black & White
•
Operates on Cable TV channel 59 - receive it on any cable ready TV
or handheld / portable TV set !
•
Superior performance - transmits up to 150 feet with small antenna
or use better receiving antenna for up to 1/4 mile !
•
Unit runs on 9 volts DC; a 9 volt alkaline battery works well!
•
Works great with our mini-peeper series of CCD Video camera
modules !
•
Dielectric resonator for fantastic frequency stability - no drifting or
tuning !
C2000
Advertisement
Related Manuals for Ramsey Electronics CUBE 2000
Summary of Contents for Ramsey Electronics CUBE 2000
- Page 1 CUBE 2000 WORLD’S SMALLEST HIGH POWER TV TRANSMITTER KIT Ramsey Electronics Model No. C2000 Transmits perfect video - and you can hide it under a quarter! Fully assembled, just add a camera and battery for a complete hide-it-anywhere video transmitter! A few years ago, only the CIA or the KGB had anything like this! •...
- Page 2 1997 by Ramsey Electronics, Inc. 590 Fishers Station Drive, Victor, New York 14564. All rights reserved. No portion of this publication may be copied or duplicated without the written permission of Ramsey Electronics, Inc. Printed in the United States of America. •...
- Page 3 Ramsey Publication No. MC2000 Manual Price Only $5.00 INSTRUCTION MANUAL FOR CUBE 2000 TV TRANSMITTER TABLE OF CONTENTS Introduction to the C2000 ......4 Hook-up ............4 Using the Cube 2000 ........6 Troubleshooting ..........8 Ramsey Warranty ........11 • C2000...
- Page 4 You will need to solder your camera video and ground wires and your Cube power supply wires to the Cube 2000. Ramsey cameras need to run on their own 12 volt DC supply. The following PC board diagram shows where the connections will be soldered.
- Page 5 1. Solder the Cube’s 9 volt positive battery wire to the solder pad labeled "RED" on the Cube and the negative 9 volt battery wire to the pad labeled "BLK" on the Cube. 2. Your camera should have three wires; Red (power +), Black (ground), Yellow (video).
- Page 6 USING THE CUBE 2000 Since the Cube transmits on Cable channel 59, not UHF TV channel 59, we must use a cable ready TV set up to receive cable and not off-air standard TV. Other small hand-held (like the Sony Watchman) and automobile TV sets with variable dial tuners (like you see for $49.95 at Sam’s Club) are capable of tuning cable channel 59,...
- Page 7 14 to receive the Cube’s signal, adjust tuning for best reception. USING YOUR CUBE OUTDOORS: While your Cube 2000 has been encapsulated to protect the precision adjustments and specialized circuits inside, the unit is not waterproof and should be enclosed in a weatherproof housing for outdoor use.
- Page 8 TROUBLESHOOTING: If you're having trouble getting your C2000 to work properly, check to be sure that: • your battery is connected correctly; red wire soldered to the pad marked "RED" and black wire soldered to the pad marked "BLK". Also be sure your solder connection is solid. •...
- Page 9 • C2000...
- Page 10 • C2000...
-
Page 11: Warranty Information
UNIT. TIME INVOLVED FOR REPAIR DEPENDS ON THE PRODUCT. IT TYPICALLY RUNS ONE TO TWO WEEKS AFTER FACTORY RECEIPT. RAMSEY ELECTRONICS, INC. RESERVES THE RIGHT TO REFUSE REPAIR ON ANY ITEM. REFUNDS YOU ARE GIVEN TEN (10) DAYS TO EXAMINE OUR PRODUCTS. IF YOU ARE NOT SATISFIED YOU MAY RETURN THE PRODUCT TO THE FACTORY FOR A REFUND. - Page 12 C2000 TV TRANSMITTER Quick Reference Page Guide Introduction to the C2000 ......4 Hook-up ............4 Using the Cube 2000 ........6 Troubleshooting ..........8 Ramsey Warranty ........11 Manual Price Only: $5.00 Ramsey Publication No. MC2000 Assembly and Instruction manual for: RAMSEY MODEL NO.
