PROGRAMMING
GENERAL
P001 Operation = 1 (level)
P006 Empty = 1.7 m (e.g. Transducer to channel bottom)
P007 Span = 1.3 m (e.g. Channel bottom to highest head)
RELAYS
Set Relay Set Up to "off" (P100=0, preset) prior to relay programming.
PARAMETER
P111 Relay Function
P112 Relay A Setpoint
P113 Relay B Setpoint
P114 Relay C Setpoint
P115 Relay D Setpoint *
*
Relay Setpoints above are for illustration purposes only. Program Relay Setpoints
as required to satisfy individual application requirements.
OPERATION
By level (as indicated by the bar graph)...
1. The Penstock is:
a) driven more open for 0.1 minute at 45% level or less (RL1).
b) driven more closed for 0.1 minute at 55% level or more (RL2).
c) control operation is limited (P115) to every 1 minute (for stabilization).
d) both controls are held "off" if the level is between 45.01% and 54.99%.
2. Alarms indicate critical operating conditions.
a) Hi Alarm = close control malfunction (on 65%, off 60%)
b) Lo Alarm = open control malfunction (on 35%, off 40%)
c) Both Alarms = HYDRO+ power interruption
3. Use the 4-20 mA output if desired...
a) proportional to level if Operation = "level" (P001 = 1).
b) inversely proportional to level if Operation = "space" (P001 = 2).
PL-507
RL#1 RL#2
63 63
*
45% 55%
*
---- ----
*
0.1 ----
1 ----
49
RL#3 RL#4 RL#5
1 1
65% 35%
60% 40%
---- ----
---- ----
0
----
----
----
----
