622 SM Port Adapter Module Description
622 SM Port Adapter Module Description
The 622 SM (single-mode) PAM, shown in Figure 4, provides connection to one OC12 interface
using a duplex SC SM fiber-optic connector.
Figure 4
622 MM Port Adapter Module Description
The 622 MM (multimode) PAM, shown in Figure 5, provides connection to one OC12 interface using a duplex
SC MM fiber-optic connector.
Figure 5
Specifications
Table 1 lists the 622 single-mode port adapter module specifications:
Table 1
Description
Dimensions (H x W x D)
Weight
Operating temperature
Nonoperating temperature
Humidity
Altitude
Interface timing
4 LightStream 1010 ATM Switch 622 SM/MM Port Adapter Module Configuration Note
622 SM Port Adapter Module
622 MM Port Adapter Module
622 SM Port Adapter Module Specifications
Specifications
PAM: 1.2 x 6.5 x 10 in. (3.0 x 16.5 x 25.4 cm)
1.10 lb (.50 kg))
32 to 104F (0 to 40C)
-40 to 167F (-40 to 75C)
10 to 90%, noncondensing
-500 to 10,000 ft (-52 to 3,048 m)
Loop timing, Stratum 4 accuracy clock for self-timing
