622 SM/MM Configuration Defaults
When the switch is powered on initially without any previous configuration data, the ATM interfaces
are configured automatically on the physical ports. ILMI and the physical card type are used to
automatically derive the ATM interface type, UNI version, maximum VPI and VCI bits, ATM
interface side, and ATM UNI type.
Default ATM Interface Configuration Without Autoconfiguration
If ILMI has been disabled or if the connecting end node does not support ILMI, the following
defaults are assigned to all interfaces:
•
ATM interface type = UNI
•
UNI version = 3.0
•
Maximum VPI bits = 8
•
Maximum VCI bits = 14
•
ATM interface side = network
•
ATM UNI type = private
The following defaults apply to the OC12 PAM:
•
Framing = sts-12c
•
Clock-source = free-running
•
STS-stream scrambling = on
•
Cell payload scrambling = on
You can accept the default ATM interface configuration or overwrite the default interface
configuration using the command line interface commands. These commands are described in the
section "Configuring Virtual Connections" in the LightStream 1010 ATM Switch Software
Configuration Guide.
To test the configuration refer to the section "Confirming the Installation" in the LightStream 1010
ATM Switch User Guide.
