ASIX AX88772A Installation Manual

Wince 5.0 driver installation guide
Hide thumbs

Advertisement

Quick Links

Download this manual
1. Product Information:
The AX88772A/AX88772 Controller is a single chip USB 2.0 to Fast Ethernet Controller. This is
an AX88772A/AX88772 NDIS driver for WinCE 5.0 embedded system. It has been qualified
under WinCE 5.0 CETK on an Intel Pentium 4 2.8GHz system with a NEC D720100AGM USB
2.0 PCI Host adapter running WinCE 5.0 CEPC X86 Platform Image.
Note: The default USB 2.0 HCD driver (EHCI) of Windows CE 5.0 Platform Builder has a
USB 2.0 device Hot-Swap BUG. The EHCI driver should be updated to fix this bug. Please
refer to Section 6 "Update WinCE 5.0 USB 2.0 HCD Driver (EHCI.DLL)" for the detail
information.
2. Files Descriptions:
The AX88772A/AX88772 WinCE driver package includes the files as described below,
RELEASE.PDF
AX88772.DLL
EHCI.DLL
PROJECT.REG
PROJECT.BIB
CETK_LOG\ 1C_TEST.LOG
CETK_LOG\ 2C_TEST.LOG
CETK_LOG\ 1C_TEST.TXT
CETK_LOG\ 2C_TEST.TXT
This file
Driver file
Updated EHCI Driver file
Sample REG file
Sample BIB file
CETK One Card Test log file
CETK Two Card Test log file
CETK One Card Test readme file
CETK Two Card Test readme file
Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation
WinCE 5.0 Driver Installation Guide
1
AX88772A/AX88772

Advertisement

loading
Need help?

Need help?

Do you have a question about the AX88772A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASIX AX88772A

Summary of Contents for ASIX AX88772A

  • Page 1 WinCE 5.0 Driver Installation Guide 1. Product Information: The AX88772A/AX88772 Controller is a single chip USB 2.0 to Fast Ethernet Controller. This is an AX88772A/AX88772 NDIS driver for WinCE 5.0 embedded system. It has been qualified under WinCE 5.0 CETK on an Intel Pentium 4 2.8GHz system with a NEC D720100AGM USB 2.0 PCI Host adapter running WinCE 5.0 CEPC X86 Platform Image.

  • Page 2: Revision History

    1. Add PHY ON/OFF procedure 2. Fix issue of ping command with big size v1.0.1.0 Mark 2009/02/12 1. Improve the performance on USB1.1 interface v1.0.0.9 Mark 2009/02/09 1. Fix EHCI hot-plug issue Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 3 4. Turn on AX88772A backpressure function when enable flow control. v1.0.0.6 Francis 2007/04/02 1. Support AX88772A chip. (Add wakeup frame and VLAN) 2. Modify to fix EHCI resume issue. 3. Change "Prefix" parameter from “NDS” to “ASX” in “project.reg” file 1.

  • Page 4: Driver Installation

    AX88772A/AX88772 WinCE 5.0 Driver Installation Guide 4. Driver Installation: 1. Add below AX88772A/AX88772 registry values into the $(_WINCEROOT)\PUBLIC \CEBASE\OAK\FILES\PROJECT.REG file. ; @CESYSGEN IF BSP_NIC_AX88772 ;IF BSP_NIC_AX88772 [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\2965_30496\Default\Default\AX88772] "DLL"="AX88772.DLL" "Prefix"="ASX" [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\2965_30506\Default\Default\AX88772] "DLL"="AX88772.DLL" "Prefix"="ASX" [HKEY_LOCAL_MACHINE\Drivers\USB\ClientDrivers\AX88772] "DLL"="AX88772.DLL" "Prefix"="ASX" [HKEY_LOCAL_MACHINE\Comm\AX88772] "DisplayName"="ASIX AX88772 USB 2.0 Fast Ethernet Driver"...
  • Page 5 "EnableDHCP"=dword:1 ;Enable DHCP function "UseZeroBroadcast"=dword:0 ;Use zero for broadcast address? ;ENDIF BSP_NIC_AX88772 ; @CESYSGEN ENDIF BSP_NIC_AX88772 2. Add below AX88772A/AX88772 driver file path and attributes into the $(_WINCEROOT) \PUBLIC\CEBASE\OAK\FILES\PROJECT.BIB file. MODULES ; Name Path Memory Type ; -------------- ----------------------------------------------------------- ----------- ax88772.dll...
  • Page 6 WinCE 5.0 Driver Installation Guide 3. Install new platform for your project YourProjectName Note: Please check if the PROJECT.REG file in $(_WINCEROOT)\PBWorkspaces \<YourProjectName>\WINCE500\CEPC_x86\OAK\files subdirectory is included all contents modified in Step 1. Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 7 6. Startup your CE/PC to get the connection with the Platform Builder. 6-1. Install a supported Ethernet adapter (like NE2000 ISA card or RTL8139 PCI card) for Ethernet Boot Loader (eboot.bin) and a ASIX AX88772A/AX88772 USB to Fast Ethernet adapter for tested WinCE driver.
  • Page 8 6-11. After the image file is downloaded successfully, the CE/PC will be booted up to WinCE operation system by running the Platform Image file. 6-12. Run Ping command to verify the network connection function. Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 9 AX88772A/AX88772 WinCE 5.0 Driver Installation Guide 5. Modify Driver Parameters: 1. Modify the AX88772A/AX88772 registry values from the $(_WINCEROOT)\PBWorkspaces \<YourProjectName>\RelDir\CEPC_x86_Release\PROJECT.REG file. ; @CESYSGEN IF BSP_NIC_AX88772 ;IF BSP_NIC_AX88772 [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\2965_30496\Default\Default\AX88772] "DLL"="AX88772.DLL" "Prefix"="ASX" [HKEY_LOCAL_MACHINE\Drivers\USB\LoadClients\2965_30506\Default\Default\AX88772] "DLL"="AX88772.DLL" "Prefix"="ASX" [HKEY_LOCAL_MACHINE\Drivers\USB\ClientDrivers\AX88772] "DLL"="AX88772.DLL" "Prefix"="ASX" [HKEY_LOCAL_MACHINE\Comm\AX88772] "DisplayName"="ASIX AX88772 USB 2.0 Fast Ethernet Driver"...
  • Page 10 ;Use zero for broadcast address? ;ENDIF BSP_NIC_AX88772 ; @CESYSGEN ENDIF BSP_NIC_AX88772 2. Choose “Make Run-Time Image” from the Build OS menu to build a new platform image (NK.BIN) to take effect the new settings. Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 11 USB 2.0 device is unplugged while there is a pending transfer. This bug has been confirmed by Microsoft and will be fixed in the future version of Windows CE 5.0. Solution: 1. ASIX provides an updated EHCI.DLL file for standard X86 CE/PC platform. 1-1. Copy the updated EHCI.DLL file into the $(_WINCEROOT)\PBWorkspaces \<YourProjectName>\RelDir\CEPC_x86_Release subdirectory.
  • Page 12 (See below picture) 2-3. Check if the EHCI.DLL file in the $(_WINCEROOT)\PBWorkspaces \<YourProjectName>\RelDir\CEPC_x86_Release subdirectory is updated successfully or not. 2-4. Run "Make Run-Time Image" to create the NK.BIN image file. Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 13 7. How to configure WinCE 5.0 to run the SROM Programming Tool? Before running AX88772A/AX88772 SROM Programming Tool (eeprom.exe), users need to add the “NDIS user mode I/O driver” in the WinCE 5.0 platform and then select “Build and Sysgen”...
  • Page 14 (0B95h/772Ah) and AX88772’s default VID/PID (0B95h/7720h). If the VID/PID of your AX88772A/AX88772 board are different from AX88772A’s/AX88772’s VID/PID, please follow below procedures to change the VID/PID registry setting of AX88772A/AX88772 WinCE 5.0 driver to support your AX88772A/AX88772 board. 8-1. Change the VID/PID setting from the Registry File 1.
  • Page 15 ==> 0 = "Disable"; 2 = "Link-up"; 4 = "Magic Packet"; 8 = "Wakeup Frame" 6 = "Link-up" & "Magic Packet"; 10 = "Link-up" & "Wakeup Frame"; 12 = "Magic Packet" & "Wakeup Frame"; 14 = "All" ps: "Wakeup Frame" is only for AX88772A chip ;=========================================================================== "ConnectionType"=dword:0 "FlowControl"=dword:3 "WakeUp"=dword:0 ;======================================================...
  • Page 16 Select Default Device and click OK. The Default Device icon will be shown up. Click HKEY_LOCAL_MACHINE>Drivers>USB>LoadClients. You will see your own VID/PID under HKEY_LOCAL_MACHINE>Drivers>USB>LoadClients. The new VID/PID setting should be here now Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 17 WinCE registry VID/PID setting note in Section 8-1 for more details.) Edit the VID/PID setting from here directly 3. Un-plug/re-plug your AX88772A board with VID (C07Ah)/PID (A277h) in this example. The AX88772A/AX88772 WinCE 5.0 driver should work fine with your AX88772A/AX88772 board now.
  • Page 18 AX88772A/AX88772 WinCE 5.0 Driver Installation Guide 9. Known Errata: None. Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
  • Page 19 AX88772A/AX88772 WinCE 5.0 Driver Installation Guide 4F, No.8, Hsin Ann RD., Hsinchu Science Park, Hsinchu, Taiwan, R.O.C. TEL: +886-3-5799500 FAX: +886-3-5799558 Email: support@asix.com.tw Web: http://www.asix.com.tw Copyright (C) 2005-2009 Reserved by ASIX Electronics Corporation...
