MCS9865 DOS Configuration Tool
User Guide
MCS9865 DOS Configuration Tool
User Guide
Revision 2.00
th
Sep. 28
, 2012
1
Copyright (C) 2009-2012 Reserved by ASIX Electronics Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCS9865 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ASIX MCS9865

  • Page 1 MCS9865 DOS Configuration Tool User Guide MCS9865 DOS Configuration Tool User Guide Revision 2.00 Sep. 28 , 2012 Copyright (C) 2009-2012 Reserved by ASIX Electronics Corporation...
  • Page 2 Revision Date Description 2009/03/25 Initial release 2.00 2012/09/28 Changed to ASIX Electronics Corp. logo, strings and contact information. 2. Changed document revision number format to “x.xx”. 3. Re-arranged the whole document descriptions. Copyright (C) 2009-2012 Reserved by ASIX Electronics Corporation...
  • Page 3: Table Of Contents

    2. Files Descriptions ................4 3. Tool Usage ..................4 4. Installation Procedures ..............5 5. Remap Serial/Parallel Ports to Customized I/O Ports ....7 6. Serial/Parallel Ports Loopback Test ..........8 Copyright (C) 2009-2012 Reserved by ASIX Electronics Corporation...
  • Page 4: Introduction

    This document provides the information about how to install the serial and parallel ports for MCS9865 PCI to Serial and Parallel I/O ports on DOS 6.22 environment. Normally any serial and parallel I/O ports can be supported by BIOS call services in DOS environment. However DOS supports only 4 serial ports (3F8h, 2F8h, 3E8h, 2E8h) and 3 parallel ports (3BCh/378h/278h).
  • Page 5: Installation Procedures

    User Guide 4. Installation Procedures The following procedure explains how to install MCS9865 serial and parallel I/O ports on DOS. Step 1: Run "gemdosin" to confirm Device detection. (Eg. MCS9865) Following information is displayed For 2 Serial and 1 Parallel Port Gemini DOS installer version 1.0.0.4 dated 03-MAR-2009...
  • Page 6 MCS9865 DOS Configuration Tool User Guide Step 3: Run "gemdosin -a -r" command to remap the MCS9865 serial/parallel ports to legacy I/O ports. Gemini DOS installer version 1.0.0.4 dated 03-MAR-2009 COM1 exists COM2 exists LPT1 exists PCI Device Configurations... Found Moschip Semiconductor pci device 9865 (1000A000) Rev00 on Bus03 Slot00...
  • Page 7: Remap Serial/Parallel Ports To Customized I/O Ports

    User Guide 5. Remap Serial/Parallel Ports to Customized I/O Ports Use the following steps to remap MCS9865 ports to customize I/O addresses. Step 1: Type "edit gmconfig.cfg" and press enter to edit the contents of config file. Step 2: You can view following information in the config file as shown below.
  • Page 8: Serial/Parallel Ports Loopback Test

    MCS9865 DOS Configuration Tool User Guide 6. Serial/Parallel Ports Loopback Test Run "gemdosin -t" command to test MCS9865 Serial or Parallel Ports. Note that need to connect external loop back connectors to the serial and parallel ports before running this test.
  • Page 9 MCS9865 DOS Configuration Tool User Guide 4F, No.8, Hsin Ann Rd., Hsinchu Science Park, Hsinchu, Taiwan, R.O.C. TEL: +886-3-5799500 FAX: +886-3-5799558 Email: support@asix.com.tw Web: http://www.asix.com.tw Copyright (C) 2009-2012 Reserved by ASIX Electronics Corporation...
