Systèmes de démarrage à distance et de sécurité
Remote Start & Security Systems
tout est à votre portée
nothing comes remotely close
G U I D E D E L ' U T I L I S A T E U R
O W N E R ' S G U I D E
MD
TM
MODÈL E
MODEL
DSP5325
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AstroStart DSP621
Summary of Contents for AstroStart DSP621
- Page 1 AstroStart ® Plateforme numérique intégrée Integrated Digital d'AstroStart ® . Platform is Directed. tout est à votre portée nothing comes remotely close Depuis créaction, Since its inception, Directed has premier de Directed est d'offrir had one purpose, to provide...
-
Page 2: Congratulations
Congratulations Congratulations on the purchase of your state-of-the-art AstroStart Digital System. Reading this Owner’s Guide prior to using your system will help maximize the use its many features. For any additional questions please contact your authorized AstroStart dealer. Note: Your system is configurable and may or may not include features such as remote start or security. - Page 3 © 2017 Directed. All rights reserved.
-
Page 4: Table Of Contents
Table of Contents Congratulations ....................1 Important Information ..................1 Government Regulations and Safety Information ........1 Your Warranty ..................1 Replacement Remote Controls ..............1 Getting Started ....................4 Charging the remote control: ..............4 Keys to using this manual ..............5 Introduction ...................... -
Page 5: Directed. All Rights Reserved
© 2017 Directed. All rights reserved. -
Page 6: Getting Started
Getting Started Your 5325-TX remote is powered by an internal rechargeable battery that can only be serviced by an authorized AstroStart dealer. Due to transit and storage time prior to your purchase, the battery charge may have depleted. To ensure proper operation, check the battery level and if not fully charged, use the provided cable to connect to the USB port on a PC/Laptop or a USB power adapter. -
Page 7: Keys To Using This Manual
Keys to using this manual Specific actions (in bold type) and style conventions are used consistently throughout this manual, they are as follows: Press: implies pushing in and the remote will play the transmit beep to send • the command. •... -
Page 8: Introduction
Introduction 5325-TX Remote Control Feature Description Display Status screen - the upper portion of the display contains status icons for the System, Siren, Alarm zones, Remote Start and Remote Control (if alarm feature installed). Text field - the lower portion of display - shows the Clock, Runtime or Temperature during Remote Start, as well as Command confirmations, Page messages and programming menus Command buttons (4) -
Page 9: Status Screen Icons
Status Screen Icons Status Screen Icons Text Field The table below describes all the status screen icons. Icon Description Lock: The doors are locked, and the included alarm features are enabled (if installed). Lock Valet: The doors are locked, and the included alarm features are disabled (if installed). - Page 10 Icon Description Remote start is active, the engine is running. Timer Start is ON; Remote Start is ON. Note: When the icon is without an arrow head: Timer Start is enabled: Remote Start is OFF. Start Valet is on - the Remote Start features are disabled. Low Temperature Mode is ON;...
- Page 11 Icon Description Bars indicate battery level is Full, ¾,½,¼ or Empty. ON while the remote control is transmitting a command. ON while the remote control is receiving a message. ON with OUT of Range fault tone to indicate the remote failed to receive a command confirmation.
-
Page 12: Using The System
Using the System Commands and Confirmations This quick reference guide only covers basic features. Advanced features and more information on your system can be found in the full on-line guide. Please visit us on-line, and search using your system’s model number (found on the front cover, the URL is located on the back cover): The remote control sends commands that control the features of your system. -
Page 13: Remote Control Command Table
Remote Control Command Table Level Basic Commands Button LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 Silent Arm/Lock (Panic)* Utility 1 Utility 3 Car Finder Arm/Lock Silent Combo Valet Disarm/Unlock Utility 2 Utility 4 Disarm/ (Start/Alarm Unlock Valet)** Remote Start** Timer Start Alarm Valet Temperature... -
Page 14: Basic Commands
Basic Commands Arm/Lock Press and release The vehicle doors lock, siren/horn sound, parking lights flash, and alarm* features are enabled. The 2-way remote control confirms by using text, icon, or tones. If an alarm zone is active (e.g. door is open) an alert message will follow. If a Valet mode is enabled the 2-way remote control confirms by using text, icon, or tones accordingly. -
Page 15: Remote Start/Stop
Remote Start/Stop Press and release Activate the remote starter. The engine and parking lights turns on and the 2-way remote control confirms the activation by text, icon and tone. or the engine and parking lights turn off and then the 2-way remote control will update to confirm shutdown. -
Page 16: Emergency Override
• Combo Valet ( x4 + ) The Combo Valet command is used to turn on/off both Alarm Valet and Start Valet together. - If both Valets are off then both will be turned on. - If one or both Valets are on, then they will be turned off. The 2-way remote control confirms by using text, icon, or tones. -
Page 17: 5325-Tx Configuration
5325-TX Configuration Operations of the 5325-TX and how it communicates messages are set in the configuration Main Menu. Navigating menus and options Navigating menus and features, changing options, and exiting are performed using the remote control buttons. The following instructions discuss how to access and configure the settings. -
Page 18: 2615-Tx Companion Remote Control
2615-TX Companion Remote Control Level Direct Access Button LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 Arm/Lock Utility 1 Utility 3 Silent Arm/Lock Car Finder (Panic)* Silent Disarm/ Combo Valet (Start/ Disarm/Unlock Utility 2 Utility 4 Unlock Alarm Valet)** Remote Start** Alarm Low Temperature Timer Start Mode**... -
Page 19: Battery Information (5325-Tx)
Battery Information (5325-TX) The 5325-TX remote control is powered by an internal rechargeable battery that can be serviced only through an authorized AstroStart dealer. The information and precautions in this section can help maximize your battery’s life and usage in providing your 5325-TX remote control with many years of trouble free operation. -
Page 20: Battery Information (2615-Tx)
Reattach the rear cover and snap together. The remote control is now ready for use. Battery Disposal AstroStart cares about the environment. If you need to dispose of the battery, please do so in accordance with your municipal requirements for battery disposal. -
Page 21: Government Regulations
Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. -
Page 22: Warning! Safety First
You must read this Owner’s Guide to familiarize yourself with the proper procedures regarding manual transmission remote starters. If you have any questions, ask your authorized AstroStart dealer. Before remote starting a manual transmission vehicle, be sure to: •... - Page 23 Interference All radio devices are subject to interference which could affect proper performance. Upgrades Any upgrades to this product must be performed by an authorized AstroStart dealer. Do not attempt to perform any unauthorized modifications to this product. Water/Heat Resistance This product is not designed to be water and/or heat-resistant.
-
Page 24: Limited Lifetime Consumer Warranty
Limited lifetime consumer warranty Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereafter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was professionally installed and serviced by an authorized Directed dealer;... - Page 25 Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State. This warranty is only valid for sale of product(s) within the United States of America and in Canada.
