REMOTE CONTROL
®
ENGINE STARTER
U S E R M A N U A L
Model 1105U
Models 2106U – 3106U
Model 3106U is equipped with
an integrated security system.
For all automatic transmission gas- and diesel-powered vehicles
(FRANÇAIS AU VERSO)
C
S
P
ONSULT
AFETY
RECAUTION SECTION
.
BEFORE USING THIS PRODUCT
S
OME FEATURES MAY REQUIRE
(N
).
ADDITIONAL MATERIAL
OT INCLUDED
PATENT NOS
CAN 1.130.426
Manufactured in Canada by:
USA 4.345.554 - 5.614.883
- 5.617.819 - 5.673.017
AND OTHER PATENTS PENDING
JULY 2004
193-127-301-10
Printed in Canada
All rights reserved © Astroflex 2004
Advertisement
Table of Contents
Related Manuals for AstroStart ASTROSTART 1105U
Summary of Contents for AstroStart ASTROSTART 1105U
- Page 1 REMOTE CONTROL ® ENGINE STARTER U S E R M A N U A L Model 1105U Models 2106U – 3106U Model 3106U is equipped with an integrated security system. For all automatic transmission gas- and diesel-powered vehicles (FRANÇAIS AU VERSO) ONSULT AFETY RECAUTION SECTION...
-
Page 2: Government Regulations
GOVERNMENT REGULATIONS This device complies with the requirements of Industry Canada (IC) - Management of Radiofrequencies, as specified in document CNR-210. Its use is authorized only on a no-interference, no-protection basis; in other words, this device must not be used if it is determined that it causes harmful interference to services authorized by IC. -
Page 3: Table Of Contents
THANK YOU FOR CHOOSING AN ASTROSTART REMOTE CAR STARTER! Just like you are, Astroflex is concerned with the environment. This is why we are suggesting you to use the two-minute runtime when you remote-start your vehicle to warm up engine fluids. -
Page 4: Safety Precautions
Make sure you comply with all local regulations, which may prohibit leaving your engine running when vehicle is unattended in a public place. • To ensure continued safe operation of your remote starter, ask your AstroStart dealer to periodically check and/or tune the remote starting system. •... -
Page 5: Safety Sequence For Manual Transmission Vehicles
SAFETY SEQUENCE FOR MANUAL TRANSMISSION VEHICLES Your remote starter was designed to force you to perform a series of actions that will ensure that the gearshift lever is in neutral position when you exit the vehicle. This series of actions is called a "safety sequence" and is aimed at preventing any remote start in situations where remote starting the engine would not be safe. -
Page 6: The Remote Control
THE REMOTE CONTROL Your remote control has been designed to fit the natural contours of your hands so that it is easier to use. It works off three long-life lithium batteries. It can control two vehicles separately. Up to four remote controls can be assigned to your vehicle. See your dealer for replacement batteries or additional remote controls. -
Page 7: Table Of Commands
TABLE OF COMMANDS OMMANDS ANIC BUTTON REMOTE TART ONTINUOUS RMING NLOCK ISARMING RUNK CTIVATE EACTIVATE ENTINEL CTIVATE EACTIVATE TILITY CTIVATE EACTIVATE TILITY CTIVATE EACTIVATE TILITY CTIVATE EACTIVATE TILITY ALET CTIVATE EACTIVATE UNTIME ETTING TART TEMPERATURE ETTING AR FINDER ISPLAY REMOTE START FAIL CODES ISPLAY ALARM CONDITION CODES OMMAND RELATED TO ARMING AND DISARMING ONLY APPLIES TO MODEL HIS CONFIRMATION IS SENT ONLY WHEN COMMAND IS REPEATED WHILE ENGINE IS ALREADY RUNNING... -
Page 8: Start Commands
RIGGER INPUT Your remote starter is equipped with a negative trigger (pulse) input. This input can be connected to another remote control device or to an AstroStart RST-2 timer output (optional), part number 310-903-502. If this input is connected, consult this device's manual or ask your technician which command controls the start/stop function. -
Page 9: Continuous Mode
CONTINUOUS MODE Continuous Mode function lets you remove the key from the ignition while leaving the engine running. This convenient feature allows you to leave your vehicle for short periods while climate controls remain on. To access Continuous Mode, send Start command while engine is idling (see S UTOMATIC page 6). -
Page 10: Low Temperature Mode
LOW TEMPERATURE MODE In Low Temperature (Sentinel) mode, system starts your engine automatically when temperature falls below a preset level. Engine will run for programmed runtime, after which system will wait 2½ hours and then start engine again if temperature is still below preset level. -
Page 11: Security System (3106U)
SECURITY SYSTEM (3106U) PROTECTION ZONES Your security system can use up to six different monitoring devices simultaneously to protect your vehicle. These devices are connected to the system on different inputs called protection zones. One of these zones can send an audible warning (7 chirps), while the other five generate an alarm condition if system is armed. -
Page 12: Operation
OPERATION Your alarm system has three different operating modes, active, semi-passive rearming and passive rearming depending on initial programming. See the relevant paragraph for the mode your system was configured in during installation. ACTIVE In active mode, the alarm must be armed and disarmed using the remote. See Table of Commands on page 5. Alarm is armed as soon as command is received, even if a zone is in violation when command is received. -
Page 13: Indicator Light
The following table shows the effect that each zone has on the rearming cycle (after 25 or 60 seconds depending on installation). Protection zone Hood Doors Additional sensor (trunk) Shock sensor Ignition Warning Applying brakes or ignition key in RUN position cancels rearming (until a door is opened, which causes rearming cycle to restart from the beginning). -
Page 14: Secondary Functions
The following table shows the meaning of zone codes (number of flashes). ZONE CODES FLASHES ZONE INDICATED System is armed. A door is/was open. Hood is/was open. Alarm condition is/was detected on shock sensor input. Key is/was in the run position. Alarm condition is/was detected on additional sensor input. -
Page 15: Lock/Unlock Commands And Alarm System Arming/Disarming
GLOSSARY IREN Siren has six different sounds, i.e., it chirps repeatedly and has six different melodies. It chirps intermittently (short repeated chirps) during a pre-alarm and continuously during an alarm condition. It can confirm arm and disarm commands with short chirps; see table in CONFIRMATION section. This function is programmable as active or inactive during installation. -
Page 16: Trunk Release
UNLOCK / DISARM Press the button, doors are unlocked and alarm is disarmed, parking lights flash and siren chirps twice to confirm command has been received and that no alarm condition was generated during your absence. If there was a violation, confirmation is different (4 flashes or chirps) to warn you. See table of alarm codes to know which zone generated alarm condition. -
Page 17: Other Commands
OTHER COMMANDS ANTITHEFT (CIRCUIT DISABLER) Programmable as Active or Inactive during installation. Your Remote Starter is equipped with an Antitheft system. This system consists of an output that controls a relay that cuts all circuits required to operate your vehicle (optional connection). “P »... -
Page 18: Alarm Condition Codes
START FAIL CODES When a remote start attempt fails, it is possible to determine what caused the failure to start. Press the buttons simultaneously. The number of times the parking lights flash corresponds to the start fail code. The table below lists the various start fail codes. Code Module has received a Stop command (remote or timer). -
Page 19: Code Learning Of Additional Transmitter(S)
CODE LEARNING OF ADDITIONAL TRANSMITTER(S) Four different remote controls can be programmed for a given vehicle. If a fifth remote is added, the first remote is deleted. Note: When the first code learning command is sent, all the old codes are cleared out. therefore if you want to add a new remote, all the old ones must be reprogrammed as well. -
Page 20: Gearshift Check Applicable To Manual Transmission Vehicles
GEARSHIFT CHECK APPLICABLE TO MANUAL TRANSMISSION VEHICLES Make sure the parking brake is operational, i.e. it has the capability of immobilizing the vehicle. If the parking brake cannot stop the wheels from turning, which is not safe, place the main switch in OFF position until the situation is rectified.
