REMOTE CONTROL
®
ENGINE STARTER
U S E R M A N U A L
Model
RSS-2514XR
For all gas- and
diesel-powered vehicles
This model may
be equipped with an
optional security system..
(FRANÇAIS AU VERSO)
C
S
P
ONSULT
AFETY
RECAUTION SECTION
.
BEFORE USING THIS PRODUCT
S
OME FEATURES MAY REQUIRE
(N
).
ADDITIONAL MATERIAL
OT INCLUDED
PATENT NOS
CAN 1.130.426
USA 4.345.554 - 5.614.883
- 5.617.819 - 5.673.017
AND OTHER PATENTS PENDING
500-10050(07-08)
All rights reserved © Directed Electronics Canada inc. 2008
Advertisement
Table of Contents
Related Manuals for AstroStart RSS-2514XR
Summary of Contents for AstroStart RSS-2514XR
-
Page 1: Remote Control
RECAUTION SECTION BEFORE USING THIS PRODUCT OME FEATURES MAY REQUIRE ADDITIONAL MATERIAL OT INCLUDED PATENT NOS CAN 1.130.426 USA 4.345.554 - 5.614.883 - 5.617.819 - 5.673.017 AND OTHER PATENTS PENDING 500-10050(07-08) All rights reserved © Directed Electronics Canada inc. 2008... -
Page 2: Government Regulations
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio / TV technician for help. Warning: Changes or modifications not expressly approved by Directed Electronics, Canada inc. could void the user's authority to operate the equipment. 188 St-François-Xavier... -
Page 3: Table Of Contents
We wish you an excellent journey with your remote engine starter! UIDE FOR The RSS-2514XR is a remote engine starter system that provides unlock features allowing remote control of door and trunk locks. These features are optional and may require additional material and/or wiring during installation. -
Page 4: Safety Precautions
• Never perform a remote start when a person or animal is inside the vehicle. • Do not allow any person or animal to remain inside the vehicle when the engine is running under remote starter control (continuous mode). •... -
Page 5: Safety Sequence For Manual Transmission Vehicles
SAFETY SEQUENCE FOR MANUAL TRANSMISSION VEHICLES Your remote starter was designed to force you to perform a series of actions that will ensure that the gearshift lever is in neutral position when you exit the vehicle. This series of actions is called a "safety sequence" and is aimed at preventing any remote start in situations where remote starting the engine would not be safe. -
Page 6: The Remote Control
A command will not be executed if you do not press button long enough except for the RSS-2514XR remote that immediately transmit when either the lock or unlock button is pressed. In that case, the command is sent at reduced power. -
Page 7: Table Of Commands
CANNOT BE EXECUTED CONFIRMATION In all cases, your Remote Starter will confirm that command has been received properly. This will be done by either sounding horn or flashing parking lights. In this manual, confirmation signals are written in an abbreviated form; for example: (horn: 1, lights: 2) Means that horn will sound once and parking lights will flash twice. -
Page 8: Start Commands
Parking lights will stay on as long as engine is running. RIGGER INPUT Your remote starter is equipped with a negative trigger (pulse) input. This input can be connected to another remote control device or to an AstroStart RST-2 timer output (optional), part number 310-903-502. -
Page 9: Turbo Mode
Refer to the table of command on page 5 to know which button to press. This command only applies when engine is kept running by Remote Starter. It is used to stop the run time, the panic mode as well as the alarm condition without disarming the security system. -
Page 10: Setting The Runtime
LOW TEMPERATURE MODE Press the buttons simultaneously for 2 seconds. The command alternatively activates/deactivate Low Temperature mode. In Low Temperature (Sentinel) mode, system starts your engine automatically when temperature falls below a preset level. Engine will run for programmed runtime, after which system will wait 2½ hours and then start engine again if temperature is still below preset level. -
Page 11: Security System (Optional)
SECURITY SYSTEM (OPTIONAL) The current section only applies to an AstroStart security system (added as an option) which must not be confused with the vehicle’s OEM system. PROTECTION ZONES Your security system can use up to six different monitoring devices simultaneously to protect your vehicle. These devices are connected to the system on different inputs called protection zones. - Page 12 Effect on rearming cycle These three zones prolong rearming cycle as long as they remain in violation. Activated by ignition key: Activated by remote starter: This zone cancels rearming completely. No effect Cancels rearming No effect...
- Page 13 This code is repeated until you apply the brakes. Effect on rearming cycle These four zones prolong rearming cycle as long as they remain in violation. Activated by ignition key: Activated by remote starter: No effect MEANING Cancels rearming No effect...
-
Page 14: Zone Codes
The following table shows the meaning of zone codes (number of flashes). ZONE CODES FLASHES ZONE INDICATED System is armed. A door is/was open. Hood is/was open. Alarm condition is/was detected on shock sensor input. Key is/was in the run position. Alarm condition is/was detected on additional sensor input. -
Page 15: Lock/Unlock Commands And Alarm System Arming/Disarming
GLOSSARY IREN Siren has six different sounds, i.e., it chirps repeatedly and has six different melodies (supplied only with optional alarm kit). It chirps intermittently (short repeated chirps) during a pre-alarm and continuously during an alarm condition. It can confirm arm and disarm commands with short chirps; see table in CONFIRMATION section. This function is programmable as active or inactive during installation. -
Page 16: Trunk Release
UNLOCK / DISARM Refer to the table of command on page 5 to know which button to press Doors are unlocked and alarm is disarmed, parking lights flash and siren chirps twice to confirm command has been received and that no alarm condition was generated during your absence. If there was a violation, confirmation is different (4 flashes or chirps) to warn you. -
Page 17: Other Commands
ANTITHEFT (CIRCUIT DISABLER) Programmable as Active or Inactive during installation. Your Remote Starter is equipped with an Antitheft system. This system consists of an output that controls a relay that cuts all circuits required to operate your vehicle (optional connection). -
Page 18: Car Finder
Start command ignored because hood is open. Safety sequence not valid during start sequence. Start command ignored because key is in the run position. Remote starter main switch is "OFF" or output overload. Runtime has elapsed. Remote starter attempted to start engine three times unsuccessfully. -
Page 19: Code Learning Of Additional Transmitter(S)
ALARM CONDITION CODES Use this command to identify which zone is in violation during arming or which generated alarm condition. Refer to the table of command on page 5 to know which button to press. Parking lights will flash number of times corresponding to code for protection zone in violation. If more than one zone is in violation, code for the zone with highest priority is shown (1 = highest priority). -
Page 20: Gearshift Check Applicable To Automatic Transmission Vehicles
Contact your service center. • Make sure that the parking brake is applied. • With gearshift in P, start vehicle with remote starter. • Remain in vehicle and be ready to apply brakes. • Without applying brakes, move gearshift out of P.
