The Linktropy Monitor displays link statistics, throughput graphs, and the ARP table. To access the
Monitor, click on Linktropy Monitor to the right of the row of tabs in the Configuration window.
The Monitor opens in a separate browser window.
To switch between statistics and ARP table pages, click the corresponding link at the top of the
Monitor.

9.1 Statistics

The statistics page displays real-time statistics and throughput graphs of the traffic over the
emulated link. Traffic from LAN A to LAN B is shown on the top half of the page and traffic from
LAN B to LAN A is shown below. For each direction, there is a summary of the current emulation
settings, a table of statistics, a graph of the transmission rate, and a table of average transmission
rates. The currently running emulation parameters are also displayed.
All statistics are based on values since the last reset and are independent of whether the Monitor
has been open or not. Rebooting or power cycling the device resets all values. The reset button at
the top of the page resets values for the window. After reset, transmission rates are displayed in
the table only after data is available for their respective intervals.
The page is refreshed at the rate set in the drop-down menu in the upper right corner.
The reset button resets statistics for its browser window only. Opening a new
Monitor/Schedule window will restore statistics from the last reboot or power cycle.
Reloading the current window also restores all statistics.
Statistics cannot be recovered after a reboot or power cycle of the device.
