6.4 Ethernet Ports

By default, all Ethernet ports are set to auto-negotiate the proper speed and duplex settings. On
the 10/100/1000baseT emulation ports, auto-negotiation can be disabled and the ports forced to
a particular setting via the drop-down menu. However, it is strongly recommended to keep the
interfaces set to auto-negotiate unless auto-negotiation is not working properly.
Jumbo frames of up to 9 KB are supported on the Linktropy Mini-G. Jumbo frames are not
supported on the Linktropy Mini
A separate Ethernet port, labeled MGMT, is used for device management and monitoring. Auto-
negotiation cannot be disabled on the management port.
If full-duplex is selected manually, the device the port is connected to must be forced
to the same setting.
