4
L
INK
L E
INK MULATION
The Link Emulation tab contains all of the parameters for link emulation. Each parameter can be
configured separately for traffic from LAN A to LAN B and from LAN B to LAN A.
Basic parameter settings are always visible on the Link Emulation tab. Advanced parameters,
which generally only need adjustment for specialized conditions, are hidden by default. To display
the advanced parameters, click the show link. Click the hide link to hide them again if desired.
The active configuration is not modified until the Apply Changes button at the bottom of the tab
is pressed. The Apply Changes button is grayed out when there are no changes to apply. It is also
grayed out if there are any invalid entries. To return to the active configuration without applying
any changes, press the Clear Changes button.
When the Apply Changes button is pressed, final validation of the configuration is performed. If
there are no errors in the configuration, the new configuration will take effect and the message,
"Configuration Updated" will be displayed in the Message Bar. If there are any errors in the
configuration, a red box will be displayed around the invalid field or an error message will be
displayed in the Message Bar.
Advanced parameter settings are used in the emulation, even if the parameters are
hidden.
S 4 L E
ECTION INK MULATION
L E P
INK MULATION ARAMETER
E
MULATION
P
ARAMETER
T :
AB
C
ONFIGURATION
T :
AB
C
ONFIGURATION
14
