IP Address Configuration via the Linktropy GUI
To configure the management interface using the Linktropy GUI:
 Configure a PC running a supported web browser with the IP address 10.0.0.2 or other
address on the 10.0.0.0/255.0.0.0 subnet.
 Connect an Ethernet cable between the PC and the MGMT port of the Linktropy WAN
emulator.
 Open the browser on the PC and enter http://10.0.0.10 (the preconfigured management
address) in the address bar. The Linktropy End User License Agreement will be displayed in a
separate window.
Review the License Agreement. The Linktropy GUI will be displayed once the License

Agreement is accepted.
 The Linktropy GUI will open to the Device Settings tab. If desired, modify the IP address,
netmask, and default gateway for the management interface. Click the Apply Changes button
when done.
Using the provided DB-9 cable, connect the serial port of a PC running terminal emulation
software to the
baud, 8 bits, no parity, 1 stop bit, and disable flow control. For more details on connecting
to the serial console, see the Linktropy Mini
Press
[ENTER]
password.
linktropy login: admin
Use the following commands to set the IP address, IP netmask, and default gateway of the
Linktropy management interface:
mgmt set addr <interface-ip-address> netmask <ip-netmask>
mgmt set gw <default-gateway>
IP addresses and netmasks are entered in dotted-decimal format. For example:
linktropy> mgmt set addr 192.168.1.1 netmask 255.255.255.0
Once the management interface has been configured, use the Ethernet cable to connect the

MGMT port to the management network.
S 2 G S
ECTION ETTING TARTED
I L WAN E
NSTALLING THE INKTROPY
IP Address Configuration via the Serial Console
port of the Linktropy Mini
CONSOLE
to display a login prompt. At the prompt, log in as "
:
MULATOR
2
. Set the serial port parameters to 9600
2
or Linktropy Mini-G Hardware Guide.
". There is no
admin
9
