Operation
The Linktropy WAN emulator is installed between two LAN segments (or two individual devices)
using the ports labeled LAN A and LAN B. The Linktropy WAN Emulator acts as a bridge or
router between those two LAN segments. Frames
received on one port are subjected to the
emulated WAN conditions before being forwarded
to the opposite port.
Emulated WAN conditions are configured in the
Linktropy GUI. To set the emulation parameters,
use a web browser to connect to the Linktropy GUI
at the IP address of the management interface. All emulation parameters are found on the Link
Emulation tab. Emulation is disabled until the "Emulation On/Off" button at the top of the screen
is pressed. See the following chapters for details on Linktropy emulation parameters or click the
buttons on the GUI for information on specific parameters.
Registration
For access to firmware upgrades, documentation, and other support materials, register your unit
on-line at: http://www.apposite-tech.com/register.html.
Registered users will receive email notification whenever new firmware images are released.
S 2 G S
ECTION ETTING TARTED
I L WAN E
NSTALLING THE INKTROPY
:
MULATOR
