Configuring Call Control - HPE FlexNetwork MSR Series Configuration Manual

Item
Third Rule in the Match Order

Configuring call control

Configuring a number group
When you configure call control, first configure a number group and numbers in the group, and then
bind the local numbers, call routes, or IVR numbers to the number group.
1. Add a number group:
a. Select Voice Management > Dial Plan > Call Authority Control from the navigation tree.
The number group page appears.
Figure 621 Number group page
a. Click Add.
The number group configuration page appears.
Description
rule once a digit cannot be matched uniquely.
•
Priority—Number priorities are divided into 11 levels numbered
from 0 to 10. The smaller the value is, the higher the priority is.
That means level 0 has the highest priority.
•
Random selection—The system selects at random a number
from a set of qualified numbers. After the random selection rule is
applied, there are no number selection conflicts. The random
selection rule can only serve as a rule with the lowest priority or
serve as a unique rule separately.
•
Longest idle time—The longer the voice entity is idle, the higher
the priority is.
You can select one to three rules to form a sequence. The voice
gateway first selects a number according to the first rule. If the voice
gateway fails to decide which number should be selected according to
the first rule, it applies the second rule, and so on.
By default, the match order of rules for the number selection is exact
match-> priority-> random selection.
242
