RELACART UR-220D Installation And Operation Manual
Hide thumbs
Also See for UR-220D:
- Installation and operation manual (10 pages) ,
- Installation and operation manual (13 pages)
Subscribe to Our Youtube Channel
Related Manuals for RELACART UR-220D
Summary of Contents for RELACART UR-220D
- Page 1 UR-220D / UB-200 Series Professional UHF Wireless Boundary Microphones Installation and Operation...
- Page 2 Contents Introduction………………………………………………………………………… ………………… ……..P3 Thank you for choosing a RELACART professional wireless microphone system. You have joined thousands of other satisfied customers. Our years of professional experience of design and Receiver Installation and Connections……………………………………………… ………… ……….P4 manufacturing to ensure our products' quality, performance and reliability.
- Page 3 Introduction Receiver Installation and Connections ①EIA-standard metal 1U - rack receiver chassis, antenna diversity. Installation: ②Bright and easy-to-read LCD display shows RF/AF, diversity strengths; transmitter battery level; ①For better operation the receiver should be at least 3ft. 1m above the ground and at least 3ft. meanwhile, can set up selective channel, frequency, mute and other working status.
- Page 4 Receiver Controls and Functions Figure A: UR-220D Receiver Front Panel ⑤A Channel SET Button: Use in conjunction with the Up / Down arrow buttons to step through menus, choose operating frequency and select receiver function options. ⑥A Channel Infrared Data Transfer Button (SYNC): Press this button to transmit A channel data from receiver to transmitter.
- Page 5 Receiver System Setup ① Turn down the AF level of the associated mixer or amplifier, and make sure that any transmitters are Figure B: UR-220D Receiver Rear Panel turned off. ②Turn on the receiver, the LCD displays the preset data.
- Page 6 Specifications UR-220D Receiver ④To enter the menu mode: Press and hold the Set button 3 seconds to enter the edit mode, touch ﹤/﹥ button once to select and set DISPLAY, MODE, LOCK or SQELCH ( note: only DISPLAY and MODE can cooperate with UB-200 ).
- Page 7 ·Semi-cardioid polar pattern. ·Ultra-quiet electronic switch can be set to any of three operating modes: "touch on / touch off”, "touch-to-talk" and "touch-to-mute" (only cooperates with wireless receiver UR-220D & UR-220S). ·RFI-shielding technology offers rejection of radio frequency interference (RFI).
- Page 8 UB-200 Semi-cardioid Condenser Wireless Boundary Microphone Transmitter Battery Installation: Element:Fixed-charge back plate, permanently polarized condenser Polar Pattern:Half-cardioid (cardioid in hemisphere above mounting surface) Carrier Frequency Range:490MHz~860 MHz Modulation Mode:FM Frequency Response:50-17,000 Hz Max.Deviation Range :±45 KHz Operating Range:60M typical ( in open space) Current Consumption:90mA, typical RF Power Output:30mW Dynamic Range (Typical):>...
