- Page 1 ER-5700, ER-5900 UHF DUAL CHANNEL WIRELESS MICROPHONE SYSTEM Installation and Operation...
-
Page 2: Table Of Contents
Contents 01 Safety Operation and Notice ..................... Thank you for choosing a RELACART professional wireless microphone system. You have 02 System Performance Feature ....................joined thousands of other satisfied customers. Our years of professional experience of 03 Receiver Installation Method .................... -
Page 3: Safety Operation And Notice
” indicates that dangerous voltage constituting a risk of electric shock is present within this unit. 21. All Relacart products will be afforded one year free maintenance except for man-made damage, such as: antenna power supply voltage. It can be connected to the Relacart classic Antenna distribution system, —... -
Page 4: Receiver Installation Method
Receiver Installation Method Packing List ER-5700: ER-5900: Installation: Wireless microphone receiver *1 Wireless microphone receiver *1 ① For better operation the receiver should be at least 3ft (1m). above the ground and at least 3ft (1m). Wireless transmitter Wireless transmitter away from a wall or metal surface to minimize reflections. -
Page 5: Receiver Front Panel Function Introduction
Receiver Front Panel Function Introduction (ER-5700) Power switch: Turn on the receiver of power supply, long press to turn off the receiver. “SYNC” button: When the infrared frequency window of the receiver and transmitter is aligned, press the “SYNC” button, synchronization of transmitters via IR interface from receiver. -
Page 6: Receiver Rear Panel Function Introduction
Receiver r Panel Function Introduction Transmitter Function Introduction Handheld microphone (EH-38) Handheld microphone (EH-59) Anti-pull device: used to fix the connecting cable of the external power adapter. DC IN socket: connect to external power adapter. RF antenna diversity BNC input connector: suitable for connection of antenna A and antenna B, and supports DC 8V/150mA power output. - Page 7 Bodypack transmitter (ET-50) Microphone Head: It is the important part to transfer sound into audio signal. The microphone head is separate to change other microphone head if needed. LCD display: display the frequency, channel, mute and battery life. Battery indicator displays a maximum of 4 bar segments.
-
Page 8: Desktop Gooseneck Microphone (Ud-2)
Desktop gooseneck microphone (UD-2) Antenna For transmitting a bodypack radio carrier. Power toggle switch: Toggle this switch to turn on or off power supply of the transmitter. AF/INS audio input selection switch: The transmitter can be connected with an audio input device (microphone or instrument connection cable) at the top part-the input socket. -
Page 9: Transmitter Battery Installation
Transmitter Battery Installation (EH-38) Microphone rod: bending gooseneck design, can flexibly put the pickup head to any position. Speaking Aperture: When you open the microphone to speak, this instruction light bright. Gain knob: adjust the input signal size. Low cut switch: cut off the low-frequency signal below 150Hz. Battery Door Switch: Open the battery door by sliding the switch. -
Page 10: System Setup
System Setup (ET-50) Receiver Setup 1. Make sure the transmitter is off before turning on the receiver. 2 Press the power switch on the receiver, LCD backlight will turn bright, and the normal display will be in 1-2 seconds. If the screen shows more than two signals, which means that there is a frequency interference from outside, please change the other operating frequency. -
Page 11: Operating Menu Of The Receiver
▼ , the screen freshes OFF, finally press SET to confirm, the lock status is released. (4) REVISI ( display version ): select “REVISI”, then press SET to enter version mode, display current version information. Operating menu of the Receiver: (ER-5700) (ER-5900) SQELCH 10dB 40dB Adjusting the squelch threshold Minimum Squelch / : 10dB~40dB;... - Page 12 0 grid. If not, you can repeat this action until a clean channel is found. (As shown microphone, the “AF” signal in the display jumps to indicate that there is an audio output. (As below) shown below) (ER-5700) (ER-5900) (ER-5700) (ER-5900) 3.
-
Page 13: Technical Specification
Technical Specification ER-5700, ER-5900 Dual Channel Receiver EH-38, EH-59 Handheld Microphone Main Frame Size : EIA standard 1U Carrier Frequency Range: 521.25MHz ~ 936.85MHz Dual Channel PLL Synthesized Receiving Channel: Oscillation: Frequency Stability : ±0.005% (-10 C ~ 50 RF Output Power :... - Page 14 ET-50 Bodypack Transmitter UD-2 Desktop Gooseneck Microphone Carrier Frequency Range: 521.25MHz ~ 936.85MHz Carrier Frequency Range: 521.25MHz ~ 936.85MHz PLL Synthesized PLL Synthesized Oscillation: Oscillation: RF Output Power : 5mW/30mW RF Output Power: 10mW / 25mW Carrier Deviation: 0.5KHz Carrier Deviation 0.5KHz Harmonic Radiation: ≤45dB...
