TeachLogic Quantum II Owner's Manual page 9

Quantum II
owner's manual transmitter
Quantum II (IRC-360) specs.
Receiver Input Infrared FM
Modulation FM Wide-band
Reception Frequencies Ch. A: 2.08 MHz
Ch. B: 2.54 MHz
Infrared Wavelength 850 nm
Tone Signal Ch. A: 32.768 KHz
De-emphasis 50 µs
Frequency Response 50 Hz, -13KHz, C 3dB
S/N Ratio ›65 dB
THD ‹1% @1KHz
Nominal Deviation ± 10 KHz
Maximum Deviation ± 25 KHz
External Sensor Input Two, RCA
Connectivity Coverage 60 Ft. Line of Sight
Aux Inputs 3.5mm with Gain Control, Front Panel
Line Output 3.5mm with Gain Control, Front Panel
Equalization Tone Control, ± 6dB
Power Output 30 Watts (RMS) Class D Amplifier
External Speaker Output 15 Watt / 4ohm
External Connection Two Terminal Phoenix Connector
Power Supply 19VDC /3.4A / 65W CE,CSA & UL
Listed
Dimensions 6 1/4" W x 14" H x 4 3/4" D
Weight 4 lb. 2oz.
power supply (AC-36) specs.
Type Regulated Switching Power Supply
Input Voltage 100–240 volts AC, 47–63Hz
Output Voltage 19 volts DC, 3.4A
Power Output 65 watts Max.
12
Sapphire transmitter (IRT-55) specs.
Transmitting Diodes Six
Operating Range 1,600 Ft ². 60 Ft. Line of Sight
Battery Discharge Indicator
Blue Full
Purple Medium
Red Low
Flashing Red Very Low Battery
Battery Used Lithium-ion (3.7V / 620mAh)
Battery Life Approx. 8-9 Hrs/Charge
External Power Charger DC +5V, Micro USB Connector
Transmission Angle Conical
User Controls
Power Switch (push) On/Off
Mute Switch (push) On/Off momentary push
Mic Switch (3 position) HI,MID,LOW
Aux. Vol./Gain Increase, Decrease
Security Alert 5 second hold of priority button
External Aux. Input 3.5mm Line Level
Dimensions 3 5/8" H x 1¼" W x ¾" D
Weight 1.4 oz. Including battery
Handheld transmitter (IRH-35) specs.
2 Channel Switchable Field Switchable
Transmitting Diodes Ten
Modulation FM Wide-Band
Pilotone Frequency 32.768 KHz
Peak Deviation ± 25KHz
Operating Range 1600 Ft². 60 Ft.
Power Switch (Slide) On/Off
Battery Charge Level (LED) Green (Useable Charge)
Red (Needs Charging)
Battery Life Approx. 7 Hr./Charge
Dimensions 2 1/8" Dia. Head,
1 7/16" Dia. Body, 9 5/8" H
Weight 10.3 oz. w/ Battery
drop-in battery charger (BRC-60) spec
Charging Port
2 Sapphire, 1 Handheld
Red LED
Battery being charged
Green LED
Battery fully charged
Power Supply
5 VDC, 1 Amp
Dimensions
6 3/8" L x 3 3/8" W x 3 3/8" H
Weight
6.3 oz.
13
