TeachLogic Quantum II Owner's Manual page 6

Quantum II
owner's manual
infrared microphone/transmitters
The infrared microphone/transmitter is comprised of a microphone input, signal processing
circuits and several emitting diodes that transmit the vocal signal to the sensor.
The microphone/transmitter can be the Sapphire or Handheld. The rechargeable batteries
will provide 6–8 hours of service per charge. Place the microphone/transmitter in the charger
for overnight charge and it will be ready for another day's use.
The drop-in battery chargers are specifically designed to recharge lithium & NiMH batteries
at an optimum rate for maximum operating capacity and extended service life. Charger will
automatically start charging the batteries upon insertion and will shift to a maintenance
charge when batteries are fully charged.
features
• Elegant design
• Only 1.4 oz. including bat-
tery
(IRT-55) sapphire transmitter
• Long life "Lithium ion"
battery
The Sapphire's vocal clarity is unsurpassed. Its
• Rechargeable via USB cable
high level output is achieved by the unidirectional
to computer
(Cardioid) microphone and a unique free air
• Battery level indicator –
suspension system. With a built-in breath filter, the
Back light under power
Sapphire can function as a pass around hand mic.
switch
The strategic alignment of the emitting diodes
• Momentary mute button,
backlight blinks in mute assures reliable connectivity throughout the room
mode
without static or drop out.
• Push "on/off " power
With a tap on the power button, the microphone
• Channel "A" or "B" select-
is muted for private conversation—tap again to
able
restore to normal operation. The auxiliary input
• Three level microphone vol-
allows wireless playback of your iPod™ through the
ume switch (low, medium,
Sapphire. A three position slide switch provides
high)
selection of low, medium, or high microphone
• Auxiliary input (3.5mm)
sensitivity.
• Wear with a lanyard or slide
directly on neckline collar
6
words of caution and limitations of infrared
Be sure that the path of transmission between the emitter and sensor is not obstructed.
The Sapphire pendant transmitter will not function if placed in pocket.
Infrared will not work outdoors in sunlight.
Dark surfaces will not reflect infrared well and can limit distance of transmission.
Rooms larger than 1600 Sq. Ft or have high ceilings can begin to exceed the ultimate
performance of the Quantum II.
If dropouts are experienced in areas, as additional sensor ICS-55 sensor can extend the system
performance.
features
• Condenser microphone
element
• Power "on/off " switch
• Battery level indicator—
LED
• Channel "A" or "B" select-
able
• 10 high-power emitting
diodes
• Diodes at top and bottom
of handle for increased
Coverage (2 Top aimed
out, 6 Bottom 360°,
2 Bottom aimed down)
• 360º IR radiation for as-
sured connectivity
• Two "AA", Duracell, re-
chargeable NiMH batteries
2
IRH-35 handheld transmitter
The Handheld Microphone Transmitter (IRH-
35) is most applicable for student use or direct
presentation. It has an "on/off" switch and a
battery level indicator LED; Green=useable charge,
Red=low battery. The transmitter has 10 emitting
diodes: 8 around the bottom of the handle, and 2
toward the top of the handle. The metal housing
provides low handling noise and insures durable
longevity.
7
