Quantum II
owner's manual transmitter
-9
table of contents
About Infrared ............................................................
Product Description ...................................................
Assembly and Installation ..........................................
Quantum II Controls .................................................
Sapphire Microphone/Transmitters IRT-55 .............
Handheld Microphone/Transmitter IRH-35 .............
Drop-in Chargers BRC-60/Ceiling Sensor ICS-55 ...
Installation of Ceiling Sensor .....................................
Operation of Wireless Microphone .........................
Troubleshooting ..........................................................
General Specifications ...............................................
Microphone Specifications ........................................
Five Year Limited Warranty .......................................
1
2
3
4&5
6
7
8
9
10
11
12
13
14
4
a brief word about infrared
Infrared is a light ray that is below the visible
spectrum, just like the sound spectrum extends
beyond your hearing ability. An example of infrared
transmission is the remote control for your TV set.
When a button is pressed, a beam of infrared light
is emitted by a Light Emitting Diode (LED) from the
IR transmission
remote control. It is detected by a receiving diode
in your TV set. When you press a certain command
The IR transmitter
on your control, the internal electronics cause the
transmits directly to the
infrared light to flicker in a programmed sequential
sensor. However; due to
pattern (called modulating the light beam). The
the strength of the IR
modulated infrared beam is detected by the
transmitter, the infrared
receiving diode and is electronically decoded. The
signal will bounce off the
walls, ceiling and floor for
decoded signal activates the circuitry to perform
reception thus providing
the command function on your TV set.
continuous connectivity
throughout the room.
So
Benefit: total freedom
communication system you are about to start
of movement within the
using? The microphone/transmitter has several
room with no restriction
Light Emitting Diodes (LED) that emit infrared light
of orientation.
beams to the sensor located in the corner of the
room. Now when you talk into the microphone, the
microphone element modulates the light beam,
causing it to flicker in sync with your speech. The
"What's said in
sensor detects the sequential signal and the
the room, stays in
electronic circuitry in the Quantum II converts that
sequential signal into a line level analog audio
the room".
signal. Now that audio signal can be fed into an
amplifier. The amplifier magnifies the electronic
Infrared will not
signal and sends it to the speakers. This causes the
penetrate a solid surface
speaker cone to move in sync with your voice. The
thus preventing any
speaker replicates your voice and disperses your
transmission from
voice evenly throughout the room.
going out of the room.
how does this apply to the infrared
