TeachLogic Quantum II Owner's Manual

Hide thumbs Also See for Quantum II:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, User Manual
owner's manual
Infrared Wireless Microphone System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum II and is the answer not in the manual?

Questions and answers

Related Manuals for TeachLogic Quantum II

Summary of Contents for TeachLogic Quantum II

  • Page 1 owner’s manual Infrared Wireless Microphone System...

  • Page 2: Safety Instructions

    Congratulations on the purchase of your new All safety and operation instructions should be read Quantum II Infrared Wireless Microphone Sound before operating this TeachLogic product. System. You can be assured that the Quantum II fulfills all specifications and was produced to very Retain Instructions high...
  • Page 3 “What’s said in sensor detects the sequential signal and the the room, stays in electronic circuitry in the Quantum II converts that sequential signal into a line level analog audio the room”. signal. Now that audio signal can be fed into an amplifier.

  • Page 4: Product Description

    Quantum II. The AUX IN level controls the individual audio input. The audio will then be fed to • Insert the DC plug into the power input jack and place the Quantum II into the bracket, secure each end with the bolt and washer provided.
  • Page 5 Quantum II owner’s manual quantum controls quantum II controls • Channel A turns power “on/off” (red LED features indicator) and adjusts the volume of the IR microphone assigned to it. Normally the Pendant 1. Threaded insert for wall transmitter is assigned to channel A. When the mount bracket.
  • Page 6 Rooms larger than 1600 Sq. Ft or have high ceilings can begin to exceed the ultimate performance of the Quantum II. The drop-in battery chargers are specifically designed to recharge lithium & NiMH batteries If dropouts are experienced in areas, as additional sensor ICS-55 sensor can extend the system at an optimum rate for maximum operating capacity and extended service life.

  • Page 7: Sensor Cable

    Locate and install the sensors for optimum IR reception, run the cable to the sensor input on top of Quantum II system. sensor cable ICS-55 A Cable connects the sensor to the receiver. The cable is dual-shielded with a male RCA connector on each end and is plenum rated.

  • Page 8: Operation Of Wireless Microphone

    “on” but there is no LED lights when turned system operation sound “on” • On Quantum II set Ch A & B volume controls to Check if system has • off (counter clock wise) been unplugged • Turn the Quantum II “ON”, Blue LED will light Check circuit breaker •...
  • Page 9 Quantum II owner’s manual transmitter Sapphire transmitter (IRT-55) specs. Quantum II (IRC-360) specs. Transmitting Diodes Operating Range 1,600 Ft ². 60 Ft. Line of Sight Receiver Input Infrared FM Modulation FM Wide-band Battery Discharge Indicator Blue Full Reception Frequencies Ch. A: 2.08 MHz Ch.

  • Page 10: Five Year Limited Warranty

    Quantum II owner’s manual five year limited warranty notes TeachLogic IR products are guaranteed to be free Date of Purchase: of defects in workmanship or material for a period of five (5) years from date of original purchase, Model Number: subject to the following conditions: 1.
  • Page 11 1688 Ord Way Oceanside, CA 92056 0018 • • • sales@teachlogic.com 1283 • • • 8/4/15 www.teachlogic.com...
