Page 1: Installation Instructions
Installation Instructions Discover y Touch-Control Induction ® Cooktop Models DYTT305N and DYTT365N Part No. 109374 Rev. A... -
Page 2: Table Of Contents
Dacor dealer or the Dacor Customer Service Team. contains the appliance model/serial numbers and electrical requirements. For repairs to Dacor appliances under warranty call the Dacor Distinctive Service line. When you call, be prepared with your cooktop model and serial numbers (printed on the product data label). -
Page 3: Important Safety Instructions
• Always contact the Dacor Customer Service Team when issues arise that you do not understand or cannot resolve via the Installation Manual and Use and Care Manual. (See the If You Need Help… section, previous page.) About Safety Symbols and Labels These symbols alert you to the possibility of product damage, personal injury, or death if you ignore safety instructions. - Page 4 Important Safety Instructions General Precautions, cont. WARNING • Concerning cooktop service/maintenance: - Before service, verify that power to the cooktop is turned OFF at the circuit-breaker panel or fuse box. - Before installing/servicing unit, switch power off at the service panel, then lock the panel to prevent power from being switched on.
-
Page 5: Installation Specifications
Installation Specifications Electrical Specifications Location Requirements • Dacor recommends installing a non-combustible material IMPORTANT on the wall behind the cooktop. • To avoid a fire hazard, do not install the cooktop between This appliance’s electrical-connection lead wires may two tall cabinets. -
Page 6: Cooktop Clearance/Ventilation
18 square inches into the enclosure. Overhead Ventilation To reduce smoke accumulation and the risk of personal injury, Dacor strongly recommends installing a range hood above the cooktop. The hood should cover the cooktop entire surface and proj- ect at least 5 inches beyond the bottom of any overhead cabinets. -
Page 7: Appliance Dimensions
Installation Specifications Appliance Dimensions All tolerances: ±1/16 (±1.6 mm), unless otherwise stated This section contains pertinent appliance dimensions that will help you plan for the countertop cutout and under-counter clearances. • Chassis depth is 1/2” wider and deeper at the base of the glass cooking surface. •... -
Page 8: Cabinet Cutout Dimensions
Installation Specifications Cabinet Cutout Dimensions See the following page for flush and downdraft vent installation cutouts. All tolerances: +1/16 (+1.6 mm), -0, unless otherwise stated. Cabinet Clearances Model DYTT305 30” (76.2 cm) 28 3/4” (73.0 cm) DYTT365 36” (91.4 cm) 34 3/4”... - Page 9 Installation Specifications Cabinet Cutout Dimensions, cont. All tolerances: +1/16 (+1.6 mm), -0, unless otherwise stated. Countertop Inset-Cutout Dimensions Countertop Flush-Cutout Dimensions—for Down-Draft Vent (top view) IMPORTANT (Flush Cutout—for Down-Draft Vent) • See the previous page for minimum clearances to com- bustibles and overhead cabinets.
-
Page 10: Installation Instructions
• DYTT Induction Glass Cooktop • Foam tape • Hold-down brackets (2) • Glass scraper (PN 82499) • Dacor Cooktop Cleaning Creme (PN A300) • Product literature If any item is damaged/missing, contact your dealer imme- diately. Do not install a damaged/incomplete appliance. - Page 11 Installation Instructions Three-Wire Electrical Connection IMPORTANT No white-wire connection is needed for this 3-wire appli- ance. If the junction box has a neutral (white) wire, you must shield it to comply with the National Electrical Code. 1. Separate the wires coming out of the appliance conduit. 2.
-
Page 12: Verifying Proper Operation
• Following directions in the Use and Care Manual, clean Proper installation is the homeowner’s responsibility. The the cooking surface. importance of proper installation of your Dacor cooktop cannot be overstated. 1. Turn on power to the cooktop at the circuit-breaker The installer should review this checklist to ensure the panel or fuse box. -
Page 13: Wiring Wiagram
Wiring Diagrams... - Page 14 Wiring Diagrams...
- Page 15 Notes...
- Page 16 Dacor ● 14425 Clark Avenue, City of Industry, CA 91745 ● Phone: (800) 793-0093 ● Fax: (626) 403-3130 ● www.dacor.com...
