From a neighbor’s phone, immediately call the gas ating this or any other appliance. supplier. Follow the gas supplier’s instructions. • Always contact the Dacor Customer Service Team • If you cannot contact the gas supplier, call the fire about problems and conditions that you don’t under- department.
Important Safety Instructions General Safety Precautions WARNING To reduce the risk of fire, electric shock, or serious injury • Do not leave the cooktop unattended while in use to or death when using your appliance, follow basic safety avoid the possibility of a fire. precautions, including the following: •...
Important Safety Instructions Electrical Requirements Gas Supply Requirements • Be certain that the cooktop being installed is correct WARNING for the gas service being provided (Natural Gas or LP gas). Also, if using the cooktop at an altitude above To prevent an electric shock hazard, the power supply 4000 ft.
Installation Specifications WARNING Observe all governing codes and ordinances during planning and installation. Contact your local building department for further information. Product Dimensions All tolerances: ±1/16” (±1.6 mm) unless otherwise noted. Model DYCT304G 30” (76.2 cm) Chassis height Bottom of spill tray to top of cooking surface 4”...
Page 7
Installation Specifications Model DYCT365G 36” (76.2 cm) Chassis Bottom of spill tray to height top of cooking surface 4” 2 1/8” (10.2 cm) (5.4 cm) 33 5/8” * (85.4 cm) 21” (53.3 cm) 19 1/2” * (49.5 cm) * Including raised embosses on sides of chassis Front of cooktop Gas inlet Power cord in...
This appliance is to be used in conjunction with a suit- • The gas supply piping, gas shut-off valve, and the elec- able vent hood or approved Dacor downdraft vent. trical outlet must be located so they do not interfere Minimum Required Clearances with the cooktop after it is installed.
Page 9
Installation Specifications Cutout Dimensions All tolerances +1/16” -0” (+1.6 mm) unless otherwise noted. Countertop Cutout View Rear wall Vertical combustible surface 4 1/4" (10.8 cm) min. from mounting surface to combustibles below cooktop chassis Min. distance to combustible side Countertop Cutout 1 7/8"...
Ensure that the arrow on the regulator points in the If any parts are missing, see the Replacement Parts List direction of the gas flow, toward the cooktop. section on page 12 for Dacor Customer Service and • Do not apply excessive pressure when tightening gas ordering information.
Installation Instructions Assembling the Burners WARNING • Never attempt to operate the cooktop with any of the burner parts removed. • Do not attempt to adjust the burner air mixture settings. All adjustments are preset at the factory. 1. Remove the burner heads, burner rings, burner caps, and grates from their shipping packages. 2.
3. Turn on power to the electrical outlet at the circuit available when you call. See inside cover for location. breaker or fuse box. Dacor is not responsible for the cost of correcting problems 4. Press and turn ONE burner control knob slowly left to caused by a faulty installation.
Proper installation is the responsibility of the homeowner. The importance of proper installation of your Dacor cooktop cannot be overemphasized. □ Is the electrical outlet for the cooktop grounded and...
Replacement Parts List Replacement Parts List Replacement parts can be obtained by contacting Dacor Customer Service. Model DYCT304G Dacor Customer Service See the Burner Parts and Cooktop Layout on right Phone: (800) 793-0093 (U.S.A. and Canada) Burner Part Dacor P/N Monday —...
Page 15
Replacement Parts List Burner Parts Grate Feet Cap cover Cap cover (bottom view) Burner head Burner cap Line up this notch with Burner skirt the igniter Wide side Igniter down Burner head * Burner base Single Burner * Burner head on SimmerSear Assembly SimmerSear™...
Wiring Diagrams WIRING DIAGRAM 120V, 60Hz. DYCT304G POWER SUPPLY CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION VERIFY PROPER OPERATION WHEN SERVICING CONTROLS. WIRING ERRORS CAN AFTER SERVICING CAUSE IMPROPER AND DANGEROUS OPERATION.
Page 17
Wiring Diagrams WIRING DIAGRAM 120V, 60Hz. DYCT365G POWER SUPPLY CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION VERIFY PROPER OPERATION WHEN SERVICING CONTROLS. WIRING ERRORS CAN AFTER SERVICING CAUSE IMPROPER AND DANGEROUS OPERATION. ISOLATOR BOARD P/N 106104 IGNITOR, NO SWITCH LR BURNER RE-IGNITOR IGNITOR, NO SWITCH...
Page 18
Dacor ● 14425 Clark Avenue, City of Industry, CA 91745 ● Phone: (800) 793-0093 ● Fax: (626) 403-3130 ● www.dacor.com...
