- Page 1 STONEX S800A GNSS Receiver User Manual NEX S800A GNSS Receiver User Manual (September 2017)-Ver.1-Rev.0 – Firmware Version: 0.22.170401 www.stonex.it...
-
Page 2: Table Of Contents
1. Brief Introduction ..................3 1.1 Introduction ........................3 1.2 Features ........................... 4 1.3 Precaution ........................4 2. S800A Surveying System ................5 2.1 S800A Receiver ......................5 2.1.1 Receiver appearance ....................5 2.1.2 The bottom of Receiver ..................5 2.1.3 Control Panel ...................... -
Page 3: S800A Gnss Receiver – User Manual
Appendix 1: S800A Receiver Specification ............26 Appendix 2: Default Radio Configuration .............. 28 Appendix 3: Copyrights, warranty and environmental recycling ....29 Appendix 4: Safety Recommendations ..............37 S800A GNSS Receiver – User Manual... -
Page 4: Brief Introduction
S800A brings you the utmost experience. One new features inside S800A is Atlas reception : Atlas is a differential corrections systems broadcasted on L-Band, allowing increase in position accuracy in area not covered by conventional Cors working under Ntrip Technology ( lack of reference stations, lack of GPRS signals, etc ). -
Page 5: Features
Transportation：during the transport, the receiver and its accessories must be reasonably placed in its transport container, to protect against shock and vibration. Specially note that S800A contains a non-removable internal Lithium Battery, whose national and international regulations must be observed and fulfilled in transportation. -
Page 6: S800A Surveying System
2. S800A Surveying System S800A surveying system consists of three main components, namely receiver, handheld and accessories. In the following parts are their introductions. 2.1 S800A Receiver 2.1.1 Receiver appearance The receiver’s dimension is 146mm*146mm*76mm, weighting 1.2kg, with its appearance as illustrated in Figure 2-1. The front side is control panel, consisting of 1 power button and 4 indicators. -
Page 7: Control Panel
2-pin LEMO port: charge for internal battery, connect adaptor. 5-pin LEMO port: connect external power supply and external radio 7-pin LEMO port: connect PC or handheld, USB+serial port 2.1.3 Control Panel Control Panel is illustrated in Figure 2-3. S800A GNSS Receiver – User Manual... - Page 8 Function descriptions of power button and indicators are shown in Table 2-1. Table 2-1 Indicator function description Indicator Status Description Power button sufficient When the S800A receiver is powered on, power the power indicator will be lit. According Fast flashing to battery power, the power indicator (1s): low power shows...
- Page 9 When receiver has connected to other connected and instruments by Bluetooth and is receiving is receiving differential data, the led will be flashing. differential When receiver doesn’t use Bluetooth, the data. led won’t be lit. Off: connection S800A GNSS Receiver – User Manual...
-
Page 10: Mode View And Mode Switch
Self-check functionality is to check whether every module works normally. When S800A receiver has indicators off or module doesn’t work normally, you can use self-check to inspect the receiver. S800A self-check consists of four parts, namely GPS, radio, WIFI and Bluetooth. The self-check results will be voice broadcasted in the process. -
Page 11: Standard Accessories
These two containers have similar appearances but their insert layouts are different. (S800A containers are still under production.) 2.2.2 Adaptor S800A receiver adopts internal battery. You can use adaptor to charge the receiver. S800A receiver and handheld share the same adaptor model as illustrated in Figure 2-12. -
Page 12: Uhf Antenna
2-15) is in need. Figure 2-15 UHF antenna UHF antennas have 3 models, respectively covering 3 frequency ranges as shown in Table 2-6. Table 2-6 UHF antenna models Model QT410A-1 QT440A-1 QT450A-1 Frequency (MHz) 410~430 430~450 450~470 S800A GNSS Receiver – User Manual... -
Page 13: 7-Pin Serial Cable
One end of the 7-pin serial cable, the 7-pin serial port, is to connect the receiver, and the other end of the cable, the USB and the D89 interface are for data communication respectively with PC and handheld as illustrated in Figure 2-16. Figure 2-16 7-pin serial cable S800A GNSS Receiver – User Manual... -
Page 14: Other Accessories
Other accessories include glass mounting pole, controller holder, connector, tray and measuring tape and other accessories. Figure 2-17 Glass fiber mounting pole Figure 2-18 Controller holder Figure 2-19 Connector Figure 2-20 Tray Figure 2-21 Measuring tape S800A GNSS Receiver – User Manual... -
Page 15: Field Surveying
• surveying, land information, real estate surveying, geophysical prospecting, surveying and building construction in small and medium- sized cities and towns, which should meet the accuracy demand of D or E class GPS measurement. S800A GNSS Receiver – User Manual... -
Page 16: Static Surveying Operation
Power off the receiver after finishing data logging, and then transmit the data and do the indoor data processing. (See detailed operation procedures in Cube-a Software (V3.0) User Manual.) S800A GNSS Receiver – User Manual... -
Page 17: Design Principles Of Gps Control Network
Automatic start Click “Device” - “Working mode”, choose “Static”. At parameter settings, choose auto record static data and at the next time when the receiver is S800A GNSS Receiver – User Manual... -
Page 18: Rtk Dynamic Measurement (Radio)
UHF antenna port of receiver; if using external radio transmission, connect the external radio to 5-pin port with 5-pin cable. （3）Power on the receiver and select base mode. S800A GNSS Receiver – User Manual... -
Page 19: Start Of Base
（1）Fix the bracket on the pole, fix the handheld to the bracket and then install the rover on the pole. （2）Attach the internal radio antenna or connect the external radio according to the chosen data link. （3）Power on the receiver and select rover mode. S800A GNSS Receiver – User Manual... -
Page 20: Configuration Of Rover
Under radio mode, frequency and protocol settings of base and rover should be the same. S800A GNSS Receiver – User Manual... -
Page 21: Rtk Dynamic Measurement (Network)
Because RTK network mode is transmitting differential data by network, differing from radio mode only on their transmission method, the installations of base and rover are similar. And owing to S800A doesn’t have internal network functionality, it’s normally not used as a network base. -
Page 22: Web Ui Application
4. Web UI Application S800A receiver has Web UI functionality. By getting access to its internal hotspot, you can easily manage it on the Web UI. As long as you have a smart phone, PC or handheld with WIFI functionality, you can easily connect to the S800A receiver to view status, download data and configure the receiver. -
Page 23: Status
In Status, you can check the current status of receiver, including position, data link, satellite and device information. You can see detailed information with respective tap as illustrated in Figure 4-1. Figure 4-1 Position information S800A GNSS Receiver – User Manual... -
Page 24: Settings
NMEA information. You can also view and download logs, and upload, download, delete and apply related configuration. You can see detailed information with respective tap as illustrated in Figure 4-2. Figure 4-2 Satellite settings S800A GNSS Receiver – User Manual... -
Page 25: Download
Figure 4-3. Figure 4-3 Backups data 4.4 Management In Management, it provides online update, device register, password modification, device disk formatting, self-test, restore factory settings and reset as illustrated in Figure 4-4. Figure 4-4 Management S800A GNSS Receiver – User Manual... -
Page 26: Device Register
You can also register device via controller. Open SurPad software on the handheld and connect the receiver. Click “About” - “Register instrument”, then input code and registration is done. S800A GNSS Receiver – User Manual... -
Page 27: Appendix 1: S800A Receiver Specification
INTERNAL RADIO Type Tx - Rx Frequency Range 410 - 470 MHz Channel Spacing 12.5 KHz / 25 KHz 3-4 Km in urban environment Maximum Range Up to 10km with optimal conditions S800A GNSS Receiver – User Manual... -
Page 28: Power Supply
3. Network RTK precision depends on the network performances and are referenced to the closest physical base station. 4. Varies with the operating environment and with electromagnetic pollution. 5. S800A Polar Version. Specifications are subject to change without notice. S800A GNSS Receiver – User Manual... -
Page 29: Appendix 2: Default Radio Configuration
Appendix 2: Default Radio Configuration The S800A uses a single UHF radio to cover the different the whole band 410-470 MHz. The frequency and protocol can be easily modified via controller. Frequency (MHz) Channel number 451.000 452.000 453.000 454.000 455.000 456.000... -
Page 30: Appendix 3: Copyrights, Warranty And Environmental Recycling
Appendix 3: Copyrights, warranty and environmental recycling Copyrights and trademarks © 2017, STONEX Limited. All rights reserved. ® STONEX , the STONEX logo, and S800A GNSS receiver are trademarks of ® ® STONEX ® Limited. STONEX ® Assistant, STONEX ®... - Page 31 The warranty period starts from date of first sale of the instruments. At its sole discretion, under the warranty period, STONEX Europe will repair the ® product or send parts for replacement at its expense. STONEX Europe ® agrees to repair or replace the defected instrument within thirty (30) days only if STONEX ®...
-
Page 32: Shipping Policy
® Europe repair/service procedure to achieve a better and prompt service result. Return policy Dead On Arrival instruments. All returned products have to be shipped to STONEX ® Europe representative office. The original Purchaser has a period of seven (7) days starting from date of... -
Page 33: Disclaimer And Limitation Of Remedy
Firmware/Software will operate to meet your requirements. Stonex will forward the Software/Firmware Fix to the dealer or customer. Firmware/software Fix means an error correction or other update created to fix a previous firmware version that substantially doesn’t conform to the... - Page 34 If this product fails to work as warranted above, customer’s sole and exclusive remedy shall be repair or replacement. In no event will stonex , its affiliates or suppliers be ®...
-
Page 35: Service Procedure
Accessories Accessories & Specific Parts Warranty: For Accessories provided by Stonex with the instruments S800A GNSS the following general warranty time is for reference: Batteries: 7 months. Battery chargers: 7 months. Adapters for battery chargers, Cables, Tribrach, Pole, Antennas: 2 ... -
Page 36: Environmental Recycling
(refund will be done only after check of the failure part and final approval of STONEX Europe). ® (3) If the instrument needs to be sent back to STONEX Europe for ® repair/replacement, dealer/customer has to send to STONEX ®... - Page 37 · For countries outside european union (eu) The treatment, recycling, collection and disposal of electric and electronic devices may vary in accordance with the laws in force in the Country in question. S800A GNSS Receiver – User Manual...
-
Page 38: Appendix 4: Safety Recommendations
Approval is granted by the manufacturer of the equipment. Some countries have unique technical requirements for operation in particular frequency bands. To comply with those requirements, Stonex srl may modified the equipment to be subjected to grant. S800A GNSS Receiver – User Manual... - Page 39 (7.8 inches) of the antenna. DO NOT collocate (place within 20 cm) the radio antenna with any other transmitting instruments. DO NOT operate the transmitter unless all RF connectors are secure and any open connectors are properly terminated. S800A GNSS Receiver – User Manual...
- Page 40 Do not collocate (place within 20 cm) the radio antenna • with any other transmitting device. Bluetooth/WiFi radio Module The radiated output power of the internal Bluetooth module of this equipment is far below the FCC and EU radio frequency exposure limits. In S800A GNSS Receiver – User Manual...
- Page 41 “safety standards and recommendations “published by Scientific organizations. Stonex srl therefore believes the internal wireless radio is safe for use by end users. The level of energy emitted is far less than the electromagnetic energy emitted by wireless devices such as UMTS phones. However, the use of Bluetooth/WiFi may be restricted in some special situations or place , like aircraft , hospital ,etc.
- Page 42 – If battery fluid gets into your eyes, immediately rinse your eyes with clean water and seek medical attention. Do not rub your eyes! – If battery fluid gets onto your skin or clothing, immediately use clean water to wash off the battery fluid. S800A GNSS Receiver – User Manual...
- Page 43 STONEX® SRL Via Cimabue, 39 - 20851 Lissone (MB) Tel: +390392783008 ; +390392785575 | Fax :+390392789576 www.stonexpositioning.com | info@stonexpositioning.com S800A GNSS Receiver – User Manual...
