Quick Start Guide
00825-0200-2654, Rev BE
June 2016
Rosemount
0065/0185 Sensor Assembly

Advertisement

loading

Subscribe to Our Youtube Channel

Summary of Contents for Emerson Rosemount 0065

  • Page 1 Quick Start Guide 00825-0200-2654, Rev BE June 2016 Rosemount 0065/0185 Sensor Assembly ™...
  • Page 2 June 2016 Quick Start Guide NOTICE This guide provides basic guidelines for Rosemount 0065 and 0185 Sensor models. It does not provide instructions for configuration, diagnostics, maintenance, service, troubleshooting, Explosion-proof, Flameproof, or intrinsically safe (I.S.) installations. If the Rosemount 0065 or 0185 Sensor was ordered assembled to a Rosemount Temperature Transmitter, see the appropriate Quick Start Guide for information on configuration and hazardous locations certifications.
  • Page 3 Quick Start Guide June 2016 Wiring Diagrams Figure 1. Rosemount Series 65 RTD Lead Wire Configuration Flying leads and spring-loaded adapter (termination codes 0, 1, or 3 only) Single element Dual element White White Black Blue Blue Green Terminal block (termination code 2 and 4) Single element Dual element White...
  • Page 4 June 2016 Quick Start Guide Figure 2. Rosemount Series 185 Thermocouple Lead Wire Configuration Thermocouple terminal block Single element Dual element 3(-) 3(-) 1(+) 1 (+) 6(-) 4(+) Table 1. Rosemount Series 185 Thermocouple Characteristics Limits of error Alloys Tolerance Type Sheath material Temp.
  • Page 5 Quick Start Guide June 2016 Sensor Assembly Dimensions Sensor assembly without thermowell Rosemount Rosemount 644 with Rosemount LCD display meter Head or field mount transmitters Rosemount 3144 Rosemount IP68 or IP65 connection heads 25 mm 40 mm Sensor with flying leads, terminal block, or spring-loaded adapter 11 mm...
  • Page 6 June 2016 Quick Start Guide Tubular thermowell sensor assembly Rosemount 644 with Rosemount Rosemount LCD display meter Head or field mount transmitters Rosemount IP68 or IP65, connection heads 40 mm 25 mm Sensor with flying leads or terminal block ★★ Threaded and flanged tubular ★★...
  • Page 7 Quick Start Guide June 2016 Barstock thermowell sensor assembly Rosemount Rosemount 644 with Rosemount LCD display meter Head or field mount transmitters Rosemount 3144 Rosemount IP 68 or IP 65 connection heads 25 mm 40 mm Sensor with flying leads, 11 mm terminal block, or spring-loaded adapter...
  • Page 8 June 2016 Quick Start Guide Product Certifications European Directive information A copy of the EC Declaration of Conformity can be found at the end of the Quick Start Guide. The most recent revision of the EC Declaration of Conformity can be found at EmersonProcess.com/Rosemount.
  • Page 9 Quick Start Guide June 2016 I1 ATEX Intrinsic Safety Certificate: IBExU03ATEX1066X Standards: EN 60079-0:2012, EN 6079-11:2012, EN 60079-26:2007 Markings: II 1 G Ex ia IIC T6; II 1/2 G Ex ia IIC T6; II 2 G Ex ia IIC T6; 1180 Special Conditions for Safe Use (X): 1.
  • Page 10 June 2016 Quick Start Guide 5. A suitable certified Ex d or Ex tb enclosure is required to be connected to temperature probes with Enclosure option "N". 6. Care shall be taken by the end user to ensure that the external surface temperature on the equipment and the neck of DIN Style Sensor probe does not exceed 130 °C.
  • Page 11 Quick Start Guide June 2016 Figure 3. Rosemount 0065 Sensor Assembly Declaration of Conformity...
  • Page 12 June 2016 Quick Start Guide...
  • Page 13 Quick Start Guide June 2016...
  • Page 14 June 2016 Quick Start Guide China RoHS Rosemount 0065/0185 List of Rosemount 0065/0185 Parts with China RoHS Concentration above MCVs Hazardous Substances Hexavalent Polybrominated Polybrominated Part Name Lead Mercury Cadmium Chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (Cr +6) (PBB)
  • Page 15 Quick Start Guide June 2016...
  • Page 16 Emerson FZE P.O. Box 17033, Emerson.com/en-us/pages/Terms-of-Use.aspx. Jebel Ali Free Zone - South 2 The Emerson logo is a trademark and service mark of Emerson Electric Co. Dubai, United Arab Emirates Rosemount and Rosemount logotype are trademarks of Emerson Process +971 4 8118100 Management.
