('VOLT') VOLTAGE
VOLT
VOLT mode will scroll display the voltage from the
selected power source. (e.g '9.4V BATTERY' or '15.2V
DC IN'). Please note AEOS will automatically give
you a warning if the voltage drops too low which
indicates a battery change is needed (e.g. 'Low
Battery'). AEOS will also put a blinking dot on the
bottom right of the current display to indicate
Low Battery Voltage whilst reducing the output by
progressive steps of 10% until voltage stabilises to
eliminate fl icker.
AEOS will operate from 6V DC up to 17.5V DC.
Only connect external power sources with the
correct polarity and voltage to avoid serious damage
to AEOS.
(In 'VOLT' mode, to check your battery performance
in action, you can click the right switch and then
rotate the left knob to observe the actual battery
voltage during the range of dimming)
Click the left switch to return to MENU, alternatively
you can return to the basic operation (BRI / COL) by
pressing both control switches together.
('CAL') CALIBRATED CUSTOM COLOUR MODE
CAL
Click the right switch to enter 'CAL' mode. The two
rotary knobs individually control the Blue channel
LEDs ('b' XX), or the yellow channel LEDs ('y' XX).
You can now set very specifi c colours by balancing
the two colour channels, within an expanded range
of colour from 2800 kelvin up to 7200 kelvin. This
custom colour value is held as an operating preset
whilst you operate the AEOS, but will be reset if you
power the unit down.
It is very useful to have an accurate colorimeter
(such as a Sekonic C-700) to create these custom
colours.
Click the left switch to return to MENU, alternatively
you can return to the basic operation (BRI / COL) by
pressing both control switches together.
