CNTL
D M X
TECH
You can also choose to work in reverse, i.e. you
creatively choose an Aperture (i.e. f-3.0) and match
your light to your camera exposure settings, this
way all the photos from your shoot will have the
same grain structure/depth of fi eld/etc.
novel and very useful way of working creatively and
also can save a lot of time.
Click the left switch to return to MENU, alternatively
you can return to the basic operation (BRI / COL) by
pressing both control switches together.
('CNTL') CONTROL
(In 'CNTL' submenu, you can change the control
mode from local or DMX, and set the active DMX
channels for 'BRI' and 'COL').
In 'MENU', Navigate to 'CNTL' using the left knob.
Click the right switch to enter 'CNTL'.
'MODE' is displayed, select using the right switch,
click the right switch to select Local Control ('locl')
or DMX slave mode ('dmx').
Exit to MENU by pressing left switch.
To set the DMX active channels navigate to 'DMX'
by rotating left knob, select using right click, 'bri'
will be displayed, use right switch to enter then
rotate right knob to change DMX channel value for
'bri', when set press left switch. Rotate left knob
to navigate to 'col', right click to select, then adjust
DMX channel for colour temperature by rotating
right knob. Once set, use left switch to exit (default
'bri' DMX channel is 1, default 'col' DMX channel is
2) to exit to MENU press left switch twice.
('TECH') TECHNICAL UTILITIES MENU
(In 'TECH' submenu you can monitor battery voltage
, set up a custom calibrated colour, monitor the
operating temperature,
version)
or check the fi rmware
This is a
