Rotolight AEOS User Manual page 12

('DISP') DISPLAY
DISP
Allows the display to be set to low brightness or 'off'
to reduce power consumption/increase battery life
or for discrete usage on set.
Click the right switch to enter 'DISP'
Rotate the left knob to select the display mode:
'High' – the display will be at full brightness
'Low' – the display will be dim, reduced power
consumption
'Off' – The display will automatically switch off after 5
seconds unless a control is operated for maximum
power saving or discretion on set.
Click the left switch to return to MENU, alternatively
you can return to the basic operation (BRI / COL) by
pressing both control switches together.
('FADE') DESIGNER FADE™
(Programmable fade up / fade down for practical
'in-camera' production fade effects)
Scroll to 'FADE'
Click the right switch to enter 'FADE' mode
Rotate the right knob to adjust the fade duration
Lit with 1 x Rotolight
AEOS, Sony A6300,
Sony 10-18mm,
ISO 100, F4.0,
1/15th(tripod)
12
