- Page 1 Mediatrix 4100 Series - Hardware Installation Guide All models except 4102 v. 2.0.40.747 2017-10-20...
-
Page 2: Table Of Contents
Installation Check List Package Check List Cleaning Instructions Mounting Tools and Equipment Connectors and Indicators Bypass Feature (4108/4116/4124 Models) Installing the Mediatrix Unit Installing the Unit on a Flat Surface Installing the Unit on the Wall Connecting the Telephony Cables... - Page 3 Table of Contents Connecting the Mediatrix Unit Using a DHCP Server Connecting the Mediatrix Unit Using a Static IP Address Verifying the Installation Cables 10/100 Ethernet Connection (RJ-45) FXS Connections (RJ-11) FXS Connections (RJ21X) for Mediatrix 4124 only Troubleshooting Locating the Product Serial Number Troubleshooting LED Patterns RESET/DEFAULT Button...
-
Page 4: Safety Recommendations And Information
Mediatrix 4100 Series - Hardware Installation Guide Safety Recommendations and Information Danger, Warning, Caution, and Note Definitions Danger: Indicates a hazardous situation which, if not avoided, will result in death or serious injury. Warning: Indicates a hazardous situation which, if not avoided, could result in death or serious injury. -
Page 5: General Safety Practices
Mediatrix 4100 Series - Hardware Installation Guide Warning: This equipment must be installed and maintained by service personnel. Incorrectly connecting this equipment to a general-purpose outlet could be hazardous. Warning: This product relies on the building's installation for short-circuit (overcurrent) protection. -
Page 6: Electrostatic Discharge Prevention
Mediatrix 4100 Series - Hardware Installation Guide Warning: Do not use the telephone to report a gas leak in the vicinity of the leak. Warning: Do not get this product wet or pour liquids into it. Warning: Ultimate disposal of this product should be handled according to all national laws and regulations. - Page 7 Mediatrix 4100 Series - Hardware Installation Guide bewust te zijn van de bij elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van standaard maatregelen om ongelukken te voorkomen. Varoitus: Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa ruumiinvammaan.
-
Page 8: Requirements
Mediatrix 4100 Series - Hardware Installation Guide Requirements Location Requirements To avoid premature aging of the unit, insure user security and facilitate access, upgrades and maintenance, the following guidelines must be followed. • Install the Mediatrix unit: • on a standard 48.26 cm (19 in.) equipment rack •... -
Page 9: Mediatrix 4100 Series Characteristics
50 Hz / 60 Hz 1.6 A Power Consumption Model Voltage / Operating Current (mA) Power (W) Thermal Frequency Conditions Dissipation 4108 120 Vac / 60 All ports off hook 240 Vac / 50 All ports off hook 120 Vac / 60 All ports ringing into... - Page 10 Mediatrix 4100 Series - Hardware Installation Guide Model Voltage / Operating Current (mA) Power (W) Thermal Frequency Conditions Dissipation 120 Vac / 60 All ports 23.5 ringing into 3REN each 240 Vac / 50 All ports 23.5 ringing into 3REN each 4124 120 Vac / 60 All ports off...
-
Page 11: Getting Started
Mediatrix 4100 Series - Hardware Installation Guide Getting Started Installation Check List Task Verified by Date Network information available and recorded in site log. Location requirements verified. Site power Voltage. Installation site pre-power check completed. Mounting tools and equipment available. Additional equipment available. -
Page 12: Package Check List
Mounting Tools and Equipment Tools • ESD wrist strap Equipement • RJ-45 cables for the WAN and LAN connections • RJ-11 cable for telephony connections (for the 4108 and 4116) • RJ-21 cable (only for 4124) media5corp.com... -
Page 13: Connectors And Indicators
Mediatrix 4100 Series - Hardware Installation Guide Connectors and Indicators LEDs Behavior Condition Ready Green, steady ON All lines are enabled (operational state) media5corp.com... - Page 14 Mediatrix 4100 Series - Hardware Installation Guide Behavior Condition Green, steady OFF All lines are disabled (operational state) Blinking 1 cycle per 4 At least one line is enabled seconds, 75% duty and at least one line is disabled (operational state) In-Use Lines idled and unlocked Steady ON...
-
Page 15: Bypass Feature (4108/4116/4124 Models)
Mediatrix unit or if the Network is down, a phone/fax used on FXS connector 1 (Mediatrix 4108/4116) or analog line 1 (Mediatrix 4124) is directly connected to the SCN Bypass line. FXS connector 1 (Mediatrix 4108/4116) or analog line 1 (Mediatrix 4124) stays in Bypass connection until: •... -
Page 16: Installing The Mediatrix Unit
Mediatrix 4100 Series - Hardware Installation Guide Installing the Mediatrix Unit Before you start Warning: Before performing this procedure, you must first read and understand the Safety Recommendations listed in this document. Note: Note or take a picture of your unit's serial number before starting the installation, and place the card stickers of the cards not factory installed. -
Page 17: Installing The Unit On The Wall
Mediatrix 4100 Series - Hardware Installation Guide Next Step Connecting the Telephony Cables (p. 18) Installing the Unit on the Wall Before you start IMPORTANT: Before performing this procedure, you must first read and understand the Safety Recommendations listed in this document. Information Consider writing down the Product Serial Number on a document easy to access before performing the installation of the unit. -
Page 18: Connecting The Telephony Cables
Mediatrix 4100 Series - Hardware Installation Guide Next Step Connecting the Telephony Cables (p. 18) Connecting the Telephony Cables Information Note: To prevent damage to the Mediatrix unit, make sure to connect the cables to their proper location on the Mediatrix unit. Steps Wear an ESD wrist strap, ensuring it makes good contact with your bare skin. -
Page 19: Connecting The Mediatrix Unit Using A Static Ip Address
Mediatrix 4100 Series - Hardware Installation Guide Attach the ESD wrist strap end to an earth ground (unpainted bare metal spot of a grounded equipment rack). Make sure the circuit breakers of AC power sources used to power the Mediatrix unit are OFF. -
Page 20: Verifying The Installation
Mediatrix 4100 Series - Hardware Installation Guide Turn ON the AC power sources that are used to power the Mediatrix unit at the circuit breaker. Note: When the unit is brought from a cold to a warm environment, condensation, that might be harmful to the unit, may occur. -
Page 21: Cables
Mediatrix 4100 Series - Hardware Installation Guide Cables 10/100 Ethernet Connection (RJ-45) Caution: Always use standard telecommunication cables with a minimum of 26 AWG wire gauge. • Category 5 cables can be used for 10/100 Base T-Connections. • It is possible to use either a crossover or a straight Ethernet cable as the Mediatrix units perform automatic MDI/ MDIX detection, meaning that they adapt to the type of cables connected to them. -
Page 22: Fxs Connections (Rj-11)
Mediatrix 4100 Series - Hardware Installation Guide FXS Connections (RJ-11) Warning: The RJ-11 cable should comply with UL 1863 and CSA C22.2 No 233 standards. Caution: Use standard telecommunication cables with a minimum of 26 AWG wire gauge. The RJ-11 pair of wires is wired so that pins 3 and 4 are connected to the Ring and Tip, which meets the EIA/TIA-IS 968 and CS-03 Issue 8, Part III requirements. - Page 23 Mediatrix 4100 Series - Hardware Installation Guide Line Ring 1(with bypass) pin1 pin26 pin2 pin27 pin3 pin28 pin4 pin29 pin5 pin30 pin6 pin31 pin7 pin32 pin8 pin33 pin9 pin34 pin10 pin35 pin11 pin36 pin12 pin37 pin13 pin38 pin14 pin39 pin15 pin40 pin16...
- Page 24 Mediatrix 4100 Series - Hardware Installation Guide Line Ring pin23 pin48 pin24 pin49 Note: Pins 25 and 50 are not used. media5corp.com...
-
Page 25: Troubleshooting
Mediatrix 4100 Series - Hardware Installation Guide Troubleshooting Locating the Product Serial Number Before you start Warning: Make sure your unit is powered off. Steps Flip the unit. The serial number is located underneath the unit. Note: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 26: Troubleshooting
Mediatrix 4100 Series - Hardware Installation Guide Flip the unit and power the unit. Troubleshooting Problem Cause Unable to contact the Management Interface. Wrong Eth port used for the Network configuration (Mediatrix unit on the edge or in the LAN with or without a DHCP server). Card does not appear in the Management •... -
Page 27: Reset/Default Button
Mediatrix 4100 Series - Hardware Installation Guide LED state Description Power LED blinking green 3 cycles per second, Waiting for DHCP (IPv4 or IPv6) answer or IPv6 50% duty router advertisement or PPPoE connection. No Ip Address configured. All LEDs blinking green, 3Hz, 50% duty Waiting for DHCP (IPv4 or IPv6) answer or IPv6 router advertisement or PPPoE connection. -
Page 28: Partial Reset
Mediatrix 4100 Series - Hardware Installation Guide Pressing Time Action Comment LED Pattern need and action to be applied. Partial Reset The partial reset provides a way to contact the Mediatrix unit in a known and static state while keeping most of the configuration unchanged. A partial reset can be performed at the initial start-up of the Mediatrix unit or on a unit already in use where the configuration was modified in such a way that the user can longer access the system by the web page or otherwise. - Page 29 Mediatrix 4100 Series - Hardware Installation Guide Service Parameter Default Value ServicesAaaType (table) Each service will be configured to use Local authentication and no accounting mechanism. EnableTelnet Disable TelnetPort EnableSsh Enable SshPort ManagementInterface Lan1 SNMP EnableSnmpV1 Disable EnableSnmpV2 Disable EnableSnmpV3 Enable Port ServerPort...
-
Page 30: Factory Reset
Mediatrix 4100 Series - Hardware Installation Guide Result The Rescue Network Interface is displayed when accessing the Management Interface. Several parameters and services are modified. What to do next Remove the changes in your configuration that caused the system to no longer respond, and do not forget to disable the Rescue Network interface (Network/Interfaces/Rescue Network Configuration table). - Page 31 Mediatrix 4100 Series - Hardware Installation Guide Note: Do not release the Reset/Default button before the LEDs stop blinking and are steadily ON. This can take up to 30 seconds. Release the paper clip. Result All configuration parameters are reset to their default value. When the Mediatrix unit has finished its provisioning sequence, it is ready to be used with a DHCP server provided IP address and MIB parameters.
-
Page 32: Standards Compliance And Disclaimers
Mediatrix 4100 Series - Hardware Installation Guide Standards Compliance and Disclaimers Supported Standards Note: The standards compliance of the Mediatrix units are printed on the same sticker as the product serial number. Category Specification Agency approvals • Anatel • European Union •... -
Page 33: Disclaimers
Industry Canada (CS-03, Issue 9, November 15, 2004) Note: Changes or modifications to your Equipment not expressly approved by Media5 voids the user’s warranty. This device complies with Part 15 of the FCC Rules and RSS-213 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 34 If you experience trouble with this telephone equipment, please contact Media5 for information on how to obtain service or repairs. The telephone company may ask that you disconnect this equipment from the network until the problem has been corrected or until you are sure that the equipment is not malfunctioning.
- Page 35 Directives 2014/30/EC and 2014/35/EC European parliament (EMC and LVD directives)is given. Any unauthorized modification of the product voids this declaration. For a copy of the original signed Declaration Of Conformity please contact Media5 at the above address.
-
Page 36: Product Disposal Instructions
For appropriate disposal and recycling instructions, contact your local Media5 Corporation provider. The Waste of Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) was established... -
Page 37: Documentation
Mediatrix 4100 Series - Hardware Installation Guide Documentation Mediatrix units are supplied with an exhaustive set of documentation. Mediatrix user documentation is available on the Documentation Portal Several types of documents were created to clearly present the information you are looking for. Our documentation includes: •... -
Page 38: Copyright Notice
Copyright ™ © 2017 Media5 Corporation. This document contains information proprietary to Media5 Corporation. Media5 Corporation reserves all rights to this document as well as to the Intellectual Property of the document and the technology and know-how that it includes and represents.
