REMOTE CONTROLLER DISPLAY

REMOTE SIGNAL
RECEIVER
MODE DISPLAY
• It displays the
operating mode.
ENERGY SAVE
• Whenever you push this
button, the cumulative power
consumption is decreased.
(Cooling mode only)
Room Air-conditioner
ROOM TEMP DESIRED TEMP
TEMP
FAN
MODE
TURBO
COOLING
TIMER
FAN
SPEED
ENERGY
SAVE
ENERGY
SAVE
POWER
5
TEMP./TIMER DISPLAY
• It displays the temperature
and the timer.
TEMPERATURE SET
• It is the button to set the
desired room temperature.
The temperature can be set
within a range from 16°C
(60°F) to 32°C (90°F) by
1°C (1°F)
MODE SELECT
• Everytime you push this
button, It is selected as
follow. (COOLING TURBO
FAN COOLING)
FAN SPEED
• Everytime you push this
button, It is selected as
follow. (High Low High)
POWER ON/OFF SWITCH
• To turn the unit ON, push
this button.
To turn the unit OFF, push
this button again.
