Part List - DAEWOO ELECTRONICS DWC-084R Service Manual

Part List

MAIN PCB ASS`Y (3114302140)
NO PART NAME
1 FUSE
2 FUSE CLIP
3 VARISTOR
4 C-LINE ACROSS
5 PIN
6 C-CERA
7 C-ELEC
8 C-ELEC
9 C-ELEC
10 RESISTOR
11 RESISTOR
12 RESISTOR
13 WAFER
14 WAFER
15 DIODE
16 DIODE ZENOR
17 C-CERA
18 CHOKE COIL
19 BUZZER
20 IC REGULATOR
21 RELAY
22 RELAY
23 TRANS SMPS
24 PCB POWER
25 DIODE BRIDGE
26 DIODE
27 IC SMPS
28 PHOTO COUPLER
SPEC
250V 50T 3.15A
AFC-520
15G561K
275V 104K
GP881205-2(187)
104Z,50VDC
470UF 35V SD
10UF 450V SD
100UF 16V SD
1/4W-1KJ
1/4W-100J
1/4W-2KJ
YW396-05AVD
SMW250-07
UF203
1N5241B
2200PF, 250V
1mH, 0.5A
DP-2520BA
KIA7805P
US11-12S
UKH-12S
264P
56X106X1.6T(FR1)
S1NB80
ST02D-200
TNY264P
TLP421
14
PARTCODE
5FVLB3152L
3107000600
D15G561K--
CLV-B3104M
3108803400
CCXE1H104M
CEXE1V477C
CEXE2W106C
CEXE1C107C
RD-4K102J-
RD-4K101J-
RD-4K202J-
3108802900
3108804100
DZUF203---
DZN5241B--
CH1BFB222K
52C102K000
3105698200
1KA7805AP-
5SC0101310
5SC0101210
5EMU1916--
3104302110
DS1NB80---
DZST02D200
1TNY264P--
1TLP421---
Q`TY LOC.
1 FUSE
2 FUSE
1 VAR
1 CL1
1 CN1
3 CC1,CC2,CC3
1 CE4
2 CE1,CE2
1 CE3
2 R2,R4
1 R3
1 R1
1 CN3
1 CN2
1 D2
1 D3
1 YC1
1 L1
1 BZ1
1 IC1
2 RL2,RL3
1 RL1
1 TRS1
1 PCB
1 BD1
1 D1
1 IC2
1 PC1
