DAEWOO ELECTRONICS DWC-084R Service Manual page 31

NO CODE COMPONENTS
29 3106000400 NUT HEX(L)
30 3100700600 BUSHING GUIDE
31 3103800400 LOCK TWIST STANDOFF
32 3100700900 BUSHING HOUSING
33 3110504200 BOX CONTROL
34 3114302160 FRONT PCB
35 3114203500 PANEL CONTROL
36 3111601500 DECO FRONT
3109507610 CAPACITOR
37
3116904000 CAPACITOR
38 3101201600 CLAMP CAPACITOR
39 7S432X4081 SCREW TAPTITE
40 3101397900 POWER CORD
41 7S432X4081 SCREW TAPTITE
42 7S432X4081 SCREW TAPTITE
43 3113537210 LABEL CIRCUIT
44 3114302140 PCB MAIN
45 7141300611 SCREW TAPPING
46 3108502900 SEAL CONTROL BOX
47 3102702010 HARNESS COMP ASSY
– OVER LOAD PROTECT
48
– OVER LOAD PROTECT
49 – GASKET
50 – COVER TERMINAL
51 – NUT
52 3108502700 SEAL EVA TOP
53 3104504800 PLATE SCROLL
54 3108503800 SEAL SCROLL
55 7122401211 SCREW TAPPING
56 3106601000 SCROLL UPPER
57 3108502800 SEAL COND TOP
58 3100078800 CABINET ASSY
59 3100605100 BRACKET CABINET
60 3104505600 PLATE WINDOW TOP
61 7112401211 SCREW TAPTITE
62 3108507600 SEAL CABINET TOP
63 3108507700 SEAL CABINET SIDE
64 3108507800 SEAL CABINET BACK
65 3108503000 SEAL CABINET FLANGE
66 7112401211 SCREW TAPPING
Q'TY SPECIFICATION
1 M6(LEFT SCREW)
1 NBR(HS 60° ±5°)
3 DASTL-3NA
1 NBR(HS 60° ±5°)
1 SGCC T0.8X332X270P REGULLAR-SP
1 TT3 TRS SE 4X8 MFZN(C/CAPACITOR)
1 ABS(5VB), HFA-451
1 PC T0.4
1 4/40µF, 370VAC, ø50
1 7/45µF,370VAC, ø50
1 SGCC T0.8X113XCOIL REGULLAR-SP
1 TT3 TRS SE 4X8 MFZN
1 SJT AWG #16X3
1 TT3 TRS SE 4X8 MFZN
1 TT3 TRS SE 4X8 MFZN
1 P.E T0.05
1 FUSE; 250V, 3.15A
4 PAN 3X6
1 F-US, 258X264XT5(D/G)
1 AWG-16,UL(BR/RD/OR)
1 KA-122-LAIN21J
1 KA-122-LAGN17H
1 SILICON
1 PC
1 HEXAGON FLANGE
1 F-US, 350X40XT5
1 PP+T30
1 F-US,115X60XT5(D/G)
3 T2S TRS 4X12 MFZN
1 EPS
1 F-US,400X30XT10
1 DWC-092C
1 SGCC
1 SECC T1.2X82.5X466.5(GY-258D)
3 T2S TRS 4X12 MFZN
1 F-US+F-PE(475X220XT10)
2 F-US(315X220XT8)
1 F-US(360X30XT15)
1 F-US(540X10XT5)
2 T1 TRS M4X12 POLY/WAS MFNI
31
DWC - ****
REMARK
064R
084R
064R
084R
PAINT
PAINT
