10. EXPLODED DIAGRAM AND PARTS LIST

DWC-064R, DWC-084R PARTS LIST
 Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
NO CODE COMPONENTS
1 3100300701 PAN BASE
2 3106002400 COMP BOLT
3 3106600401 SCROLL LOWER
4 2221040001 SEALING PUTTY
3117102410 COMPRESSOR
5
3117102500 COMPRESSOR
6 3RC8104AE0 GROMMET
7 7400208411 WASHER PLAIN
8 7392801211 NUT LOCK
3100029400 ASS'Y CONDENSOR
9
3100049700 ASS'Y CONDENSOR
10 7112401611 SCREW TAPPING
3114430800 PIPE COND IN
11
3110054700 AS PIPE COND IN
3110056100 ASS'Y PIPE CAPILLARY
12,13
3100034330 ASS'Y PIPE CAPILLARY
3100029300 ASS'Y EVAPORATOR
14
3100049600 ASS'Y EVAPORATOR
3100034500 ASS'Y PIPE EVA OUT
15
3100050000 ASS'Y PIPE EVA OUT
16 3100034410 ASS'Y PIPE EVA IN
3110054500 ASS'Y PIPE SUCTION
17
3110054600 ASS'Y PIPE SUCTION
18 7112401611 SCREW TAPPING
3108002720 MOTER FAN
19
3108003510 MOTER FAN
20 3104201500 PANEL HOUSING
21 3101402400 COVER ORIFICE
22 7S432X4081 SCREW TAPTITE
23 7122401211 SCREW TAPPING
24 3101801820 FAN BLOWER
25 3106000600 WASHER PLAIN
26 3106000500 NUT HEX(R)
27 3101801910 FAN PROPELLER
28 3106000600 WASHER PLAIN
Q'TY SPECIFICATION
1 PP+T30% or PP+CACL3(40%)
3 M8XP1.25XL57
1 EPS
0.01 GRAY(PGE000901)JOINT SEALER
1 RM5465GQ87(THACOM), 115V-60HZ
1 RM5475GQ87(THACOM), 115V-60HZ
3 EPDM 45
3 M8(ID8.4XOD22XT1.6)
3 M8XP1.25(RIGHT SCREW)
1 2RX1CX17S, P1.4
1 3RX2CX17S, P1.6
2 T1 TRS 4X16 MFZN
1 C1220T-OL. OD7.94XT0.7
1 C1220T-OL. OD7.94XT0.7
1 C1220T-O,ID1.4 X L1,200
1 C1220T-O,ID1.0 X L400 X 2
1 2RX2CX12S, P1.2
1 3RX2CX13S, P1.4
1 DWC-070C
1 DWC-091C
1 DWC-070C
1 C1220T-O,ID9.52
1 C1220T-O,ID9.52
2 T1 TRS 4X16 MFZN
1 A9525HS601-1,115V-60HZ(1000/900)
1 A9525HS602,115V-60HZ(1080/980)
1 SGCC Z-27
1 PP
4 TT3 TRS 4X8 SE MFZN
3 T2S TRS 4X12 MFZN
1 ABS ø8
1 M6(ID6.4XOD19.8XT1.6)
1 M6(RIGHT SCREW)
1 ABS+GF20%
1 M6(ID6.4XOD19.8XT1.6)
30
REMARK
064R
084R
064R
084R
064R
084R
064R
084R
064R
084R
064R
084R
064R
064R
084R
064R
084R
