Summary of Contents for Xerox Work Centre 385
- Page 1 Xerox Work Centre 385 User’s Guide...
- Page 2 Thank you for purchasing Xerox Work Centre 385—the multifunction office product for your home office and the whole family. We are sure that Xerox Work Centre 385 will provide all you need in one machine. Xerox Work Centre 385 combines these office...
-
Page 3: Important Safety Information
Important Safety Information Always be careful when using the machine. To reduce the risk of fire, electrical shock, and other injuries, keep these safety considerations in mind when installing, using, and maintaining your machine: ¥ Stability. Place the machine on a secure, stable surface. The machine can cause serious damage if it falls. -
Page 4: Set Up Your Machine
Set Up Your Machine Unpacking Machine Toner Cartridge Handset Handset cradle Printer Exit Tray Document Tray Document exit tray AC power cord Printer driver User’s Guide installation diskettes One-touch Label Telephone line cord *1 These parts may not be provided depending on country. *2 These parts may look different. -
Page 5: Control Locations And Functions
Control Locations and Functions Take a moment to familiarize yourself with the main components and understand their functions. Front View Paper Extension Paper Guides Automatic Paper Feeder Manual Paper Feeder Document Tray Control Panel Document Guides Document Exit Tray Print Exit Tray Note: Your machine may look slightly different than the illustration. - Page 6 Rear View TEL LINE Jack Power Cord Connector EXT. LINE Jack Printer Connector Inside Cover Image Cover Release Buttons (right and left) Set Up Your Machine...
-
Page 7: Choosing A Location
Choosing a Location To help guarantee trouble-free operation of your machine, place it on a flat, stable surface near your workstation. Leave enough space to allow for easy paper loading, paper out and opening the front cover. Do not place your machine: - In direct sunlight. - Page 8 Extension Phone If you want to use a regular phone or answering machine with your Work Centre 385 machine, connect the phone into the EXT.LINE jack. Plug the cord of your extension phone or answering machine into the socket marked EXT.LINE on the back of the machine.
- Page 9 Printer Cable Your Xerox Work Centre 385 has a parallel interface port, which allows you to use it with IBM PCs and compatible computers. You have to purchase a Centronics parallel interface cable that supports bi-directional communications (IEEE standard 1284). Ask your dealer for assistance if you need help selecting the right cable.
- Page 10 AC Power Cord Plug one end of the cord into the back of the machine and the other end into a standard AC power outlet. The machine turns on. If there is no cartridge installed, or no paper, the display shows ‘DOOR OPEN or NO TONER!!!’ or [NO PAPER]. outlet If you want to turn it off, unplug the power cord.
-
Page 11: Fcc Information
FCC Information The following information is applicable only to the machines installed in the United States of America. Label Identification This equipment complies with Part 68 of the FCC rules. On the rear of this equipment is a label that contains, among information, the FCC Registration Number and Ringer Equivalence Number(REN) for this equipment. - Page 12 ¥ Reorient or relocate the receiving antenna. ¥ Increase the separation between the equipment and the receiver. ¥ Connect the equipment into an outlet on a circuit different form that to which the receiver is connected. ¥ Consult the dealer or an experienced radio/TV technician for help. Fax Branding The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone fax machine...
- Page 13 IC Information The following information is applicable only to facsimile machines installed in Canada. Notices The Industry Canada(IC) label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the userÕs satisfaction.
- Page 14 Renseignements du Industrie Canada Les renseignements suivants ne sÕappliquent quÕaux tŽlŽcopieurs installŽs au Canada. Avis LÕŽtiquette du Industrie Canada(IC)est une marque dÕidentification dÕappareil certifiŽ. Cette certification signifie que l'appareil rŽpond ˆ certains crit•res de sŽcuritŽ et dÕutilisation. Cependant, le Minist•re ne peut pas garantir que l'appareil rencontrera les exigences de son utilisateur.
- Page 15 CDRH Regulation This fax is certified as a ÒClass 1Ó laser product under the U.S. department of health and human services(DHHS) radiation performance standard according to the radiation control for health and safety act of 1968. This product complies with FDA radiation performance standard, 21 CFR subchapter J.
- Page 16 Ozone Emission This fax has no corona wires and therefore does not generate ozone gas. UL Standards for Ozone A standard for ozone emissions has been established by Underwriters Laboratory (UL). This fax meets this standard when shipped from the factory to our customers. Power Saver This fax contains advanced energy conservation technology that reduces power consumption when it is not in active use.
-
Page 17: Specifications
PLEASE CHECK!! Specifications Applicable line Public Switched Telephone Network (PSTN) or behind PABX Compatibility CCITT Group 3, ECM Data coding MH/MR/MMR Modem speed 14400/12000/9600/7200/4800/2400 bps Transmission speed Approx. 6 sec. (V.17 ECM: 14.4 kbps) Effective scanning width 8.3 inches (210 mm) Effective printing width 8.2 inches (202 mm) Scanning method...
