Replaceable Mechanical Parts
Replaceable parts list
Fig. &
Tektronix part Serial no.
index
number effective
number
10-2-1 213-0882-00
-2 119-4322-00
-3 252-0571-33
-4 342-0993-00
-5 211-0722-00
-6 620-0058-XX
-7 213-0882-00
-8 366-1480-00
-9 671-3351-XX
-10 213-0882-00
-11 119-2683-XX
-12 426-2426-00
-13 210-0457-00
-14 334-3379-00
-15 441-2055-XX
-16 343-1182-00
-17 210-0586-00
-18 344-0472-00
-19 407-4394-00
-20 131-1315-01
-21 211-0325-00
-22 259-0086-XX
-23 348-1313-00
-24 426-2436-01
-25 348-1302-00
-26 640-0081-00
-27 333-4251-XX
-28 211-0722-00
-29 671-4272-XX
-30 386-6158-00
-31 671-4276-XX
-32 163-1046-XX
-33 163-1045-XX
10 6
Serial no.
discont'd Qty Name & description
6 SCREW,TPG,TR:6-32 X 0.437 TAPTITE,PNH,STL
1 FAN,TUBAXIAL:12VDC,2.4M/M,5.8MM HZO,6W,0.5A
1 PLASTIC SHEET:EXTR CHAN,5MM X 3.3MM
1 INSULATOR,FILM:PWR SPLY,POLYCARBONATE
2 SCREW,MACHINE:6-32 X 0.25,PNH,STL
1 POWER SUPPLY:185W;SWITCHING,15V/4A,12V/0.5A
4 SCREW,TPG,TR:6-32 X 0.437 TAPTITE,PNH,STL
1 PUSH BUTTON:BLK,0.328 X 0.253 X 0.43
1 CIRCUIT BD ASSY:AUX,POWER SUPPLY
2 SCREW,TPG,TR:6-32 X 0.437 TAPTITE,PNH,STL
1 FILTER,RFI:50/60HZ,250VAC,6A
1 FRAME,FAN MTG:POLYCARBONATE
1 NUT,PL,ASSEM WA:6-32 X 0.312,STL CD PL
1 MARKER,GROUND:6MM DIAMETER
1 CHASSIS ASSY:AL
1 CLAMP,LOOP:10MM ID,NYLON
2 NUT,PL,ASSEM WA:4-40 X 0.25,STL CD PL
1 CLIP,CABLE:NYLON,GRAY
1 BRKT,CMPNT,BNC:ALUMINUM,5.250 X 1.050
4 CONN, RF, JACK: BNC, FEMALE, STA, PELTORA, PANEL
MOUNT
4 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
1 FLEX CIRCUIT:BEZEL BUTTON
10 cm GASKET,SHIELD:CONDUCTIVE URETHANE FORM
1 FRAME,CRT FLTR:POLYCARBONATE
11 cm GASKET,SHIELD:CONDUCTIVE URETHANE FORM
1 DISPLAY MONITOR:7 INCH,480 X 640 PIXEL,MONO
3 PANEL,REAR:DATA OUT, STL
5 SCREW,MACHINE:6-32 X 0.25,PNH,STL CD PL,TORX,T15
1 CKT BD ASSY:CPU,A6
1 SUPPORT,CKT BD:MAT MATERIAL
1 CKT BD ASSY:CPU INTERFACE,A30
1 IC,MEMORY:CMOS,EPROM,256K X 16,
100NS,PRGM,PLCC40,SMD,U305
1 IC,MEMORY:CMOS,EPROM,256K X 16,
100NS,PRGM,PLCC40,SMD,U300
Mfr.
code Mfr. part number
0KB01 ORDER BY DESC
80009 119-4322-00
85471 ORDER BY DESC
80009 342-0993-00
0KB01 ORDER BY DESC
TK0191 620-0058-XX
0KB01 ORDER BY DESC
0JR05 ORDER BY DESC
80009 671-3351-XX
0KB01 ORDER BY DESC
TK2058 ZUB2206H-F
80009 426-2426-XX
TK0435 ORDER BY DESC
07416 ORDER BY DESC
TK0191 441-2055-XX
80009 343-1182-00
TK0435 ORDER BY DESC
80009 344-0472-00
TK0191 407-4394-XX
TK0191 131-1315-XX
0KB01 ORDER BY DESC
07416 ORDER BY DESC
80009 348-1313-00
TK1163 ORDER BY DESC
80009 348-1302-XX
80009 640-0081-00
TK0191 333-4251-XX
0KB01 ORDER BY DESC
TK0191 671-4272-XX
80009 386-6158-00
TK0191 671-4276-XX
TK0191 163-1046-XX
TK0191 163-1045-XX
