5. Safety precautions

- Caution! Laser radiation!
- Do not stare directly at the laser!
- Do not aim the unit at other people!
- Risk of eye damage!
- Laser class 2
- Power: < 1 mW
- Wavelength: 630 -670 nm

6. Ex-Data

EC type approval test certificate no.:
Ex-designation:
Approved for zone 1, device group II, gas group IIC (explosive gases, vapours or mist), temperature class T4.

7. Specifications

Measuring range
Ambient temperature Ta
Storage temperature
Relative humidity
Emission level
Smallest display unit
Target sighting
Accuracy
(at 23°C)
Repeatability
Spectral response
Response time (95%)
Batteries / power supply:
7.1 Table with type-approved batteries
Manufacturer
Panasonic
Panasonic
Duracell
Dimensions:
Weight:
CE-designation:

8. Functional description / operating instructions

Please read these operating instructions carefully so that you are familiar with, and are able to use, all of
the functions of your Ex-MP4 a. For your own safety and information please read through the instructions
on the following pages!
EPS 10 ATEX 1 242 X
† II 2 G Ex ia op is IIC T4
-18 °C to + 400 °C
0 ... +50 °C
-20 °C to +65 °C
10- 95 % r.h. non-condensing at 30 °C
fixed at 0.95
0.2 °C
Laser
-18 °C ... -1°C ±3 °C
-1°C ... +400 °C : ±2 % of reading or ±2 °C, whichever is greater
± 2 % of reading or ±2 °C whichever is greater
7-18 µm
500ms
1 x 9V alkaline battery according to IEC 6LR61, type-tested
Model
EVOLTA
Powerline
DURALOCK
152 x 101 x 38 mm
approx. 200g
‡
0102
5
