Four-Faith F-R200 User Manual page 9

Item
Standard IEEE802.11b/g/n and 802.11ac(5GHz) dual-band Wi-Fi
Bandwidth IEEE802.11b/g: 54Mbps (max)
IEEE802.11n: 150Mbps (max)
IEEE802.11ac: 867Mbps (max)
Security WEP, WPA, WPA2, etc
WPS (optional)
TX power 20dBm(11n),24dBm(11g),26dBm(11b)
RX sensitivity <-72dBm@54Mpbs
Hardware System
Item
CPU Industrial 32bits CPU
FLASH 16MB(Extendable to 32MB)
DDR2 128MB
Interface Type
Item
WAN 1 10/100/1000 Mbps WAN port(RJ45,with LED), auto MDI/MDIX,
1.5KV magnetic isolation protection
LAN 4 10/100/1000 Mbps Ethernet ports(RJ45,with LED), auto MDI/MDIX,
1.5KV magnetic isolation protection
Serial 1 RS232, RS485(RS422) port, 15KV ESD protection
Data bits: 5, 6, 7, 8
Stop bits: 1, 1.5
Parity: none, even, odd, space
Baud rate: 2400~115200 bps
Indicator "PWR", "SYS", "WIFI", "SIM", "Online","Signal Strength"
Input/Output (6) pin 3.5mm terminal block
(2) DI, (1) DO, (1) Relay
Input ON Voltage: 5 to 30 VDC
Input OFF Voltage: 0 to 3 VDC
Output < 50mA @ 30VDC
Relay:1A 250VAC/30VDC
Antenna Cellular:2 Standard SMA female interface, 50 ohm, lighting
protection(optional)
WIFI: 1 Standard SMA male interface, 50 ohm, lighting
protection(optional)
GPS:1 Standard SMA female interface, 50 ohm, lighting
protection(optional)
SIM/UIM Standard 3V/1.8V user card interface, 15KV ESD protection
Power 2PIN Terminal block reverse-voltage and over-voltage protection
, 2
(optional)
(optional)
