Summary of Contents for JENCO EC3840
- Page 1 Operation Manual Hand-held Conductivity/Salinity/TDS/ Temperature Meter EC3840...
-
Page 2: Table Of Contents
CONTENTS GENERAL INTRODUCTION………………....2 INITIAL INSPECTION……...………………....2 WATER PROOF…….……...………………....2 INSTALLING THE BATTERIES..…………....3 DISPLAY & KEYS FUNCTIONS…..……………...…………4 ..............4 A. Display ..............5 B. Keys OPERATIONAL PROCEDURES..……......5 ........5 A. Preparing Standard Solutions ............6 Calibration ........7 C. Conductivity Measurements ERROR DISPLAYS AND TROUBLESHOOTING..8 SPECIFICATIONS………………..……......9 WARRANTY…………………………......10... -
Page 3: General Introduction
All packing materials should be saved until satisfactory operation is confirmed. WATER PROOF Though the EC3840 meter is housed in a watertight case, DO NOT use it underwater. The watertight case prevents permanent damage to the unit if accidentally dropped into non-corrosive solutions. -
Page 4: Installing The Batteries
3. If the unit does not function correctly after steps1 and 2, call JENCO for possible repair or replacement (see Warranty). INSTALLING THE BATTERIES The EC3840 meter is packaged with 4 “AAA” alkaline batteries required for operation. To insert the batteries into the meter, follow the procedure outlined below. -
Page 5: Display & Keys Functions
DISPLAY & KEYS FUNCTIONS Display Figure 2: Active LCD screen 1. CONDUCTIVITY- 8. CELL- Displays when measuring Indicates conductivity cell conductivity. constant value. 9. ℃/%- Displays during calibration: ℃: Indicates temperature 2. BAT- Low battery indicator. reference unit. %: Indicates temperature coefficient unit. -
Page 6: Keys
Here are some standard solutions the user can prepare to calibrate the probe of the model EC3840. Standard solution of 1413uS at 25℃: Accurately weight out 0.746 grams of research grade dried Potassium Chloride (KCL). -
Page 7: Calibration
Standard solution of 111.9mS at 25℃: Accurately weight out 74.264 grams of research grade dried Potassium Chloride (KCL). Dissolve in 1000ml of distilled water. You can store the remaining solution in a plastic [Note: container for one week but the air space between the cap and the solution must be kept to an absolute minimum. -
Page 8: Conductivity Measurements
Note: Be certain to press “Enter” key to reset the cell constant to 0.50. If “Mode” key is pressed, the unit retains the previous cell constant and calibrates from a value that is already offset. Temperature Coefficient The unit uses the temperature coefficient to calculate temperature compensated conductivity. -
Page 9: Error Displays And Troubleshooting
Clean cell. ● Temperature > over Decrease/Increase ℃ 90.0 "over " during the sample measurements temperature. Temperature < undr ℃ -10.0 Note: If the unit still does not perform normally after the above measures are taken, call Jenco Service Department. -
Page 10: Specifications
SPECIFICATIONS Display Range Resolution Accuracy 0.0 to 499.9uS/cm 0.01uS/cm ±1% of reading + 2uS/cm 500 to 4999uS/cm 1uS/cm ±1% of reading + 5uS/cm Conductivity 5.00 to 49.99mS/cm 0.01mS/cm ±1% of reading +0.05mS/cm 50.0 to 200.0mS/cm 0.1mS/cm ±2.5% of reading + 0.5mS/cm Salinity 0.0 to 70.0ppt 0.1ppt... -
Page 11: Warranty
If you purchased the item from our Jenco distributors and it is under warranty, please contact them to notify us of the situation. - Page 12 E-Mail: jencoinfo@jencoi.com; sales@jencoi.com Website: www.jencoi.com Jenco Electronics Inc. P.O. Box Linkou 117 Taipei, Taiwan TEL: 886-2-2601-6191 FAX: 886-2-2601-7206 Shanghai Jenco Instruments, Ltd. 18 Wang Dong Zhong Road Sijing Town, Songjiang Shanghai, China TEL: 86-021-5761-9599 FAX: 86-021-5761-9598 E-Mail: jencos@jenco.com.cn Website: www.jenco.com.cn...
