Contents
1. Important Safety Instructions.......................................................................2
2.1 Package Contents.....................................................................................6
2.3 Product Diagram........................................................................................8
3. Operating and Programming......................................................................10
3.1 Notes Before Cleaning.............................................................................10
3.2 Quick Start...............................................................................................12
3.3 Cleaning Mode Selection.........................................................................15
3.4 Programming the Robot...........................................................................15
3.5 Additional Settings...................................................................................15
3.6 Optional OZMO Mopping System............................................................16
3.7 Choosing a Suction Option......................................................................17
4. Maintenance................................................................................................19
4.1 OZMO Mopping System..........................................................................19
4.2 Dust Bin and Filters.................................................................................20
4.4 Other Components..................................................................................22
4.5 Regular Maintenance..............................................................................24
5. Troubleshooting..........................................................................................25
........................................6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEEBOT OZMO 930 and is the answer not in the manual?

Questions and answers

Related Manuals for ECOVACS DEEBOT OZMO 930

Summary of Contents for ECOVACS DEEBOT OZMO 930

  • Page 1: Table Of Contents

    Contents 1. Important Safety Instructions...............2 ........6 2.1 Package Contents..................6 2.3 Product Diagram..................8 3. Operating and Programming..............10 3.1 Notes Before Cleaning................10 3.2 Quick Start....................12 3.3 Cleaning Mode Selection.................15 3.4 Programming the Robot................15 3.5 Additional Settings...................15 3.6 Optional OZMO Mopping System............16 3.7 Choosing a Suction Option..............17 4.

  • Page 2: Important Safety Instructions

    1. Important Safety Instructions When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. SAVE THESE INSTRUCTIONS 1. This Appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use...
  • Page 3 1. Important Safety Instructions 9. Do not operate the Appliance in an area where there are lit candles or fragile objects. 10. Do not use in extremely hot or cold environments (below 11. Keep hair, loose clothing, fingers, and all parts of body away from any openings and moving parts.
  • Page 4 28. When not using the Docking Station for a long period of time, please unplug it. 29. The Appliance must be used in accordance with the directions in this Instruction Manual. ECOVACS ROBOTICS cannot be held liable or responsible for any damages or injuries caused by improper use.
  • Page 5 1. Important Safety Instructions For EU Countries Correct Disposal of this Product This marking indicates that this product should not be disposed of with other household waste throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.

  • Page 6: Package Contents

    2.1 Package Contents Robot Docking Station Instruction Manual Main Brush Option Direct Suction Option Reservoir Cleaning Cloths Cleaning Cloth Plate Sponge Filter and...
  • Page 7 Model DG3G 14.8V DC Working Voltage Docking Station Model CH1630A 20V DC, 0.8A Input 100-240V AC , 50/60Hz, 25W Output Battery S01-LI-148-3200, Lithium 3200mAh, 14.8V max. power: 2.5mW Laser Frequency: 1.8KHz Rotate Speed: 300±5 circle/min Frequency bands 2412-2472MHz Output power of the WIFI module is less than 100mW.

  • Page 8: Product Diagram

    2.3 Product Diagram Robot 1. Top Cover 8. Main Brush Option 15. Reservoir 2. Control Panel 9. Driving Wheels 16. Carpet Detection Sensor 3. Anti-Collision Sensors and Bumper 10. Reservoir Slots 17. Water Outlets 11. Roller Wheel 18. Power Switch 5.
  • Page 9 Dust Bin 2. Sponge Filter 3. Dust Bin Lock 4. Dust Bin Cover 5. Dust Bin Handle Advanced OZMO Mopping System 1. Water Inlet Cover 2. Water Inlet 3. Reservoir Release Button 4. Cleaning Cloth Plate Cleaning Cloth 6. Magnet...

  • Page 10: Operating And Programming

    3. Operating and Programming 3.1 Notes Before Cleaning WARNING: Do not use DEEBOT on wet surfaces or surfaces with standing water. DEEBOT uses SMART NAVI technology (a proprietary laser scanning and operating DEEBOT, take a few moments to survey the area to be cleaned and remove any obstacles.
  • Page 11 3. Operating and Programming If there is a step or stairs in the cleaning Please be aware that DEEBOT needs at area, please operate DEEBOT to ensure its Anti-Drop Sensors can detect the drop off. It furniture without complications. may be necessary to place a physical barrier at the edge of the drop off to keep the unit from falling over the edge.

  • Page 12: Quick Start

    * Do not change the location of the Docking Station once DEEBOT has scanned the environment. If it is necessary to relocate Docking Station, power OFF DEEBOT and then power back ON so DEEBOT can re-scan the environment. Alternatively, use the ECOVACS App to direct the robot to rescan the environment.
  • Page 13 When DEEBOT completes the cleaning cycle or when battery power gets low, DEEBOT automatically returns to the Docking Station to recharge itself. DEEBOT can also be sent back to the Docking Station at any time by using ECOVACS App or by pressing the AUTO Button on the robot for 3 seconds.

  • Page 14: Power Off

    3. Operating and Programming Start Press the AUTO Mode Button on DEEBOT. DEEBOT moves around to scan the environment and build the map, and starts to work in AUTO Cleaning Mode at the same time. DEEBOT must be powered ON to clean. To choose another Cleaning Mode, please refer to section 3.3 Cleaning Mode Selection for details.

  • Page 15: Cleaning Mode Selection

    3. Operating and Programming * For models with app-connectivity, various functions can be performed using the ECOVACS App. 3.3 Cleaning Mode Selection Modes are selected using the ECOVACS App. AUTO Cleaning Mode This is the most commonly used mode. In AUTO Cleaning Mode, DEEBOT cleans in a back and forth straight-line pattern.

  • Page 16: Optional Ozmo Mopping System

    3. Operating and Programming 3.6 Optional OZMO Mopping System Cloth and a Cleaning Cloth Plate attached to a proprietary Reservoir. The Washable/Reusable * When using the mopping system, DEEBOT automatically detects and avoids the rug. * Empty any remaining water from the Reservoir and remove the Cleaning Cloth Plate before charging DEEBOT.

  • Page 17: Choosing A Suction Option

    3. Operating and Programming Start Select the desired Cleaning Mode. DEEBOT sweeps, lifts, vacuums, mops and dries in the selected mode. 3.7 Choosing a Suction Option The robot has 2 interchangeable suction options for your convenience. Main Brush Option: The best choice for deep Direct Suction Option: The best choice for cleaning with a combination of the Main Brush daily cleaning with the Main Brush removed for...
  • Page 18 3. Operating and Programming Install the Direct Suction Option Turn the robot over. Push both buttons on the Main Brush Option and remove the Main Brush Cover. Remove the Main Brush. Line up the Direct Suction Option tabs with the slots on the bottom of the robot. Press until the component clicks into place.

  • Page 19: Maintenance

    4. Maintenance Before performing cleaning and maintenance on DEEBOT, power OFF the robot and unplug the Docking Station. 4.1 OZMO Mopping System After DEEBOT finishes mopping, remove the Reservoir from DEEBOT, and maintain the Reservoir, the Cleaning Cloth and the Cleaning Cloth Plate immediately. Press the Release Button and pull to remove the Reservoir.

  • Page 20: Dust Bin And Filters

    4. Maintenance 4.2 Dust Bin and Filters Open the robot’s Top Cover and remove the Dust Bin. Open the Dust Bin Lock and empty the Dust Bin. water.

  • Page 21: Main Brush, Direct Suction Option And Side Brushes

    4. Maintenance Rinse the Dust Bin and Filter Net under Dry the Dust Bin and Filter Net completely running water. before reinstalling. 4.3 Main Brush, Direct Suction Option and Side Brushes * A Multi-Function Cleaning Tool is provided for easy maintenance. Handle with care, this cleaning tool has sharp edges.

  • Page 22: Other Components

    4. Maintenance Side Brushes Remove the Side Brushes. Remove any hair or debris tangled around the Side Brushes with the provided Multi-Function Cleaning Tool, and wipe their slots with a clean cloth. 4.4 Other Components Use the Multi-Function Cleaning Tool to cut off and remove any hair tangled around the Universal Wheel.
  • Page 23 4. Maintenance * Before cleaning the robot’s Charging Contacts and Docking Station Pins, power OFF the robot and unplug the Charging Dock. Wipe the robot’s Charging Contacts and Docking Station Pins with a dry cloth to maintain their effectiveness.

  • Page 24: Regular Maintenance

    (twice per week with pets in Every 4-6 months Filter Universal Wheel Anti-Drop Sensors Bumper Once per week Charging Contacts Docking Station Pins Note: ECOVACS manufactures various replacement parts and assemblies. Please contact Customer Service for more information on replacement parts.

  • Page 25: Troubleshooting

    5. Troubleshooting Malfunction Possible Causes Solutions DEEBOT is not powered ON. Power ON DEEBOT. Be sure that the robot’s Charging DEEBOT has not made a Contacts have made a connection with connection with the Docking the Docking Station Pins. You may Station.
  • Page 26 DEEBOT is ready for network home Wi-Fi DEEOBT was ready. setup when DEEBOT plays a musical network. slowly. Update your smartphone’s operating Your smartphone’s operating system. The ECOVACS App runs on iOS system needs to be updated. 9.0 and above, Android 4.0 and above.
