Slaughter 4320 Operation And Service Manual

500va / ac/dc hipot with ir and ground bond testers
Hide thumbs Also See for 4320:
Table of Contents

Advertisement

Quick Links

OPERATION AND SERVICE MANUAL
Model 4320, 4520
MODEL 4320 (AC/DC HIPOT WITH IR AND GROUND BOND TESTERS)
MODEL 4520 (500VA AC/DC HIPOT WITH IR AND GROUND BOND TESTERS)
SERIAL NUMBER
Models
© Slaughter Company, Inc., 2012
28105 N. Keith Drive
4320, 4520
Lake Forest, Illinois, 60045-4546
U.S.A.
Item 99-10319-01
Ver 1.11
th
Printed December 5
, 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4320 and is the answer not in the manual?

Questions and answers

Related Manuals for Slaughter 4320

Summary of Contents for Slaughter 4320

  • Page 1 OPERATION AND SERVICE MANUAL Model 4320, 4520 MODEL 4320 (AC/DC HIPOT WITH IR AND GROUND BOND TESTERS) MODEL 4520 (500VA AC/DC HIPOT WITH IR AND GROUND BOND TESTERS) SERIAL NUMBER Models © Slaughter Company, Inc., 2012 28105 N. Keith Drive...

  • Page 2: Declaration Of Conformity

    DECLARATION OF CONFORMITY Manufacturer: Slaughter Company, Inc. Address: 28105 N. Keith Drive Lake Forest, IL 60045 Product Name: 4320 Electrical Safety Compliance Analyzer Model Number: 4320 Conforms to the following Standards: Safety: EN 61010-1:2001 EN 61010-031:2002 EMC: EN 61326:1997/A1:1998 (EN 55022:1998/A1:2000 Class A,...
  • Page 3 DECLARATION OF CONFORMITY Manufacturer: Slaughter Company, Inc. Address: 28105 N. Keith Drive Lake Forest, IL 60045 Product Name: 4520 Electrical Safety Compliance Analyzer Model Number: 4520 Conforms to the following Standards: Safety: EN 61010-1:2001 EN 61010-031:2002+A1:2008 EMC: EN 61326:2006 Class A,...

  • Page 4: Warranty Policy

    Warranty Policy Slaughter Company, certifies that the instrument listed in this manual meets or exceeds published manufacturing specifications. This instrument was calibrated using standards that are traceable to the National Institute of Standards and Technology (NIST). Your new instrument is warranted to be free from defects in workmanship and material for a period of (1) year from date of shipment.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SECTION I OPERATORS MANUAL ................. 1 SAFETY ........................2 GLOSSARY OF TERMS ..................... 7 INTRODUCTION ....................... 9 SPECIFICATIONS ....................14 CONTROLS ......................27 INSTALLATION ...................... 32 QUICKSTART ......................36 OPERATION ......................40 REMOTE BUS INTERFACE: RS-232 ............... 67 OPTIONS ........................

  • Page 7: Section I Operators Manual

    SECTION 1 OPERATORS MANUAL...

  • Page 8: Safety

    SAFETY SAFETY PRECAUTIONS REQUIRED FOR HIGH VOLTAGE TESTING! GENERAL: This product and its related documentation must be reviewed for familiarization with safety markings and instructions before operation. This product is a Safety Class I instrument (provided with a protective earth terminal). Before applying power verify that the instrument is set to the correct line voltage (115 or 230) and the correct fuse is installed.
  • Page 9 The instrument and its power cord, test leads, and accessories must be returned at least once a year to a Slaughter Company authorized service center for calibration and inspection of safety related components. Slaughter Company will not be held liable for injuries suffered if the instrument is not returned for its annual safety check and maintained properly.
  • Page 10 If the instrument is used in a matter not specified by Slaughter Company, Inc. the protection provided by the instrument may be impaired.
  • Page 11 SAFETY TEST OPERATOR Qualifications This instrument generates voltages and currents which can cause harmful or fatal electric shock and must only be operated by a skilled worker trained in its use. The operator should understand the electrical fundamentals of voltage, current, and resistance.
  • Page 12 SAFETY WARNING NEVER TOUCH THE ITEM UNDER TEST OR ANYTHING CONNECTED TO IT WHILE HIGH VOLTAGE IS PRESENT DURING THE HIPOT TEST. When testing with DC, always discharge the capacitance of the item under test and anything the high voltage may have contacted--such as test fixtures--before handling it or disconnecting the test leads.

  • Page 13: Glossary Of Terms

    INTRODUCTION GLOSSARY OF TERMS (as used in this manual) Alternating Current, AC: Current which reverses direction on a regular basis, commonly in the U.S.A. 60 times per second, in other countries 50 times per second. Breakdown: The failure of insulation to effectively prevent the flow of current, sometimes evident by arcing.
  • Page 14 INTRODUCTION Leakage: AC or DC current flow through insulation and over its surfaces, and AC current flow through a capacitance. Current flow is directly proportional to voltage. The insulation and/or capacitance is thought of as a constant impedance, unless breakdown occurs.

  • Page 15: Introduction

    INTRODUCTION INTRODUCTION The importance of testing..User safety In an era of soaring liability costs, original manufacturers of electrical and electronic products must make sure every item is as safe as possible. All products must be designed and built to prevent electric shock, even when users abuse the equipment or bypass built in safety features.
  • Page 16 INTRODUCTION If, during the time the component is tested, stray current flow remains within specified limits, the device is assumed safe under normal conditions. The basic product design and use of the insulating material will protect the user against electrical shock. The equipment used for this test, a dielectric-withstand tester, is often called a "hipot"...
  • Page 17 INTRODUCTION AC testing advantages AC testing is generally much more accepted by safety agencies than DC testing. The main reason for this is that most items being hipot tested will operate at AC voltages and AC hipot testing offers the advantage of stressing the insulation alternately in both polarities which more closely simulates stresses the product will see in real use.
  • Page 18 INTRODUCTION DC testing advantages Once the item under test is fully charged the only current flowing is true leakage current. This allows a DC hipot tester to clearly display only the true leakage of the product under test. The other advantage to DC testing is that since the charging current only needs to be applied momentarily the output power requirements of the DC hipot tester can typically be much less than what would be required in an AC tester to test the same product.
  • Page 19 INTRODUCTION may under certain conditions require an IR test on the product before a Hipot test is performed. This typically is not a production line test but a performance design test. The insulation resistance test is very similar to the hipot test. Instead of the go/no go indication that you get with a hipot test the IR test gives you an insulation value usually in Megohms.

  • Page 20: Specifications

    SPECIFICATIONS Model 4320 Functional Specifications Unless otherwise stated, accuracy's are relative to a laboratory standard measurement. INPUT 115 / 230V selectable, ± 10 % variation Voltage 50 / 60 Hz ± 5% Frequency Fuse 6.3 A slow blow 250V AC...
  • Page 21 SPECIFICATIONS DIELECTRIC WITHSTAND TEST MODE ≤ 200 ms Discharge Time < 1 kV 0.08 uF < 4 kV Maximum Capacitive 1 uF Load in DC Mode 0.75 uF < 2 kV 0.04 uF < 5 kV 0.5 uF < 3 kV 0.01 uF <...
  • Page 22 SPECIFICATIONS INSULATION RESISTANCE TEST MODE Resistance Display Range: 1 - 1000 MΩ (4 Digit, Auto Ranging) Resolution: 500VDC 1000VDC MΩ MΩ MΩ 0.01 1.00 - 40.00 1.00 - 80.00 35.0 - 999.9 75.0 - 999.9 ± (3% of reading + 2 counts) Accuracy: at test voltage >...
  • Page 23 SPECIFICATIONS GROUND BOND TEST MODE Ω HI and LO-Limit Range: 0 – 510 m for 3.0 - 10.0 A Ω 0 – 200 m for 10.1 - 25.0 A Ω 0 – 150 m for 25.1 - 30.0 A Ω Resolution: ±...
  • Page 24 SPECIFICATIONS GENERAL SPECIFICATIONS Environmental Operating Temperature : 32° - 104°F (0° - 40°C) Relative Humidity: 0 to 80% Calibration Traceable to National Institute of Standards and Technology (NIST). Calibration controlled by software. Adjustments are made through front panel keypad in a restricted access calibration mode.
  • Page 25 SPECIFICATIONS Model 4520 Functional Specifications Unless otherwise stated, accuracy's are relative to a laboratory standard measurement. INPUT 115 / 230V Auto Range, ± 15 % variation Voltage 50 / 60 Hz ± 5% Frequency Fuse 15 A slow blow 250V AC DIELECTRIC WITHSTAND TEST MODE Output Rating 5 kV @ 100 mA AC...
  • Page 26 SPECIFICATIONS DIELECTRIC WITHSTAND TEST MODE ≤ 200 ms Discharge Time < 1 kV 0.08 uF < 4 kV Maximum Capacitive 1 uF Load in DC Mode 0.75 uF < 2 kV 0.04 uF < 5 kV 0.5 uF < 3 kV 0.01 uF <...
  • Page 27 SPECIFICATIONS INSULATION RESISTANCE TEST MODE Resistance Display Range: 1 - 1000 MΩ (4 Digit, Auto Ranging) Resolution: 500VDC 1000VDC MΩ MΩ MΩ 0.01 1.00 - 40.00 1.00 - 80.00 35.0 - 999.9 75.0 - 999.9 ± (3% of reading + 2 counts) Accuracy: at test voltage >...
  • Page 28 SPECIFICATIONS GROUND BOND TEST MODE Ω HI and LO-Limit Range: 0 – 510 m for 3.0 - 10.0 A Ω 0 – 200 m for 10.1 - 25.0 A Ω 0 – 150 m for 25.1 - 30.0 A Ω Resolution: ±...
  • Page 29 SPECIFICATIONS GENERAL SPECIFICATIONS Environmental Operating Temperature : 32° - 104°F (0° - 40°C) Relative Humidity: 0 to 80% Calibration Traceable to National Institute of Standards and Technology (NIST). Calibration controlled by software. Adjustments are made through front panel keypad in a restricted access calibration mode.
  • Page 30 This makes it possible to limit user access to the setup screens so that only authorized personnel can change test parameters. 2. Multiple Test Memories. The 4320/4520 provides six test memories with six steps per memory. This is beneficial for manufacturers testing multiple products on one production line. 3. Low-current sense.
  • Page 31 16. Single Step Test Mode. In this mode, the 4320/4520 can be configured to perform each test individually as a single step. This provides the manufacturers flexibility in configuring their testing procedure.
  • Page 32 SPECIFICATIONS 20. Adjustable Output Current and Milliohm Trip Currents. The 4320/4520 is versatile enough to meet a wide variety of safety agency specifications. 21. Fail Stop ON/OFF Mode. This allows the 4320/4520 to be configured to continue testing after detecting a...

  • Page 33: Controls

    CONTROLS FRONT PANEL CONTROLS 11 12 RESET BUTTON: This is a momentary contact switch used to reset the instrument. If an out-of-range reading is detected during a test, the red failure lamp within the button will light. To reset the system for the next test, press and release this button. This button may also be used to abort a test in progress.
  • Page 34 CONTROLS FRONT PANEL CONTROLS 11 12 UP ARROW (∧): Use this key to increment numeric values in the setup mode. This key also used to toggle ON/OFF functions. Also may be used to increase output voltage during a test in 10-volt increments. EXIT KEY: Use this key when you desire to enter the test mode to initiate a test.
  • Page 35 CONTROLS 4320 REAR PANEL CONTROLS 9 10 1. POSITION FOR OPTIONAL REMOTE OUTPUT JACKS: Please refer section Optional Rear Panel Controls for details. 2. FUSE RECEPTACLE: To change the fuse unplug the power (mains) cord and turn the fuse cap counter clockwise to remove the fuse.
  • Page 36 CONTROLS 9. REMOTE OUTPUT: 9 pin D subminiature female connector for monitoring PASS, FAIL, and PROCESSING output relay signals. 10. BUS INTERFACE: Optional connector for interconnection to RS-232 bus interface. 4520 REAR PANEL CONTROLS 2 3 4 1. POSITION FOR OPTIONAL REMOTE OUTPUT JACKS: Please refer section Optional Rear Panel Controls for details.
  • Page 37 CONTROLS 7. FUSE RECEPTACLE: To change the fuse unplug the power (mains) cord and turn the fuse cap counter clockwise to remove the fuse. 8. INPUT POWER RECEPTACLE: Standard IEC 320 connector for connection to a standard NEMA style line power (mains) cord. 9.

  • Page 38: Installation

    If the shipping carton is damaged, inspect the contents for visible damage such as dents, scratches, or broken meters. If the instrument is damaged, notify the carrier and the Slaughter Company customer support department immediately. Please save the shipping carton and packing material for the carrier’ s inspection. Our customer support department will assist you in the repair or replacement of your instrument.
  • Page 39 INSTALLATION turning your instrument on (model 4320 only). In addition, please be sure the correct fuse is selected and installed while the instrument is in the off position. Do not switch the line voltage selector switch located on the rear CAUTION panel while the instrument is on or operating (model 4320 only).
  • Page 40 INSTALLATION Power Cable BEFORE CONNECTING POWER TO THIS INSTRUMENT, WARNING THE PROTECTIVE GROUND (EARTH) TERMINALS OF THIS INSTRUMENT MUST BE CONNECTED TO THE PROTECTIVE CONDUCTOR OF THE LINE (MAINS) POWER CORD. THE MAIN PLUG SHALL ONLY BE INSERTED IN A SOCKET OUTLET (RECEPTACLE) PROVIDED WITH A PROTECTIVE GROUND (EARTH) CONTACT.
  • Page 41 Protect the control panel with cardboard. 4). Seal the container securely. 5). Mark the container "FRAGILE" to insure proper handling. 6). Please ship models 4320/4520 via Federal Express or UPS air. 7). Please refer in all correspondence to your RMA number. Field Installation of Options...

  • Page 42: Quickstart

    QUICK START QUICK START This quick start guide assumes the operator has some familiarity with automated hipot testing and desires to use the settings on the instrument. The default settings "default" shown will remain in memory unless you choose to override them with your own test program.
  • Page 43 QUICK START • LO-Limit: 0.00 mA • Ramp: 0.1 s • Dwell: 1.0 s • Freq.: 60 Hz • Connect:...
  • Page 44 This test will check for the condition of the ram chips, pcb's and other critical components. In addition, you will see the Slaughter Company name, Model Number, and current software version briefly appear on the LCD readout and then clear itself.
  • Page 45 QUICK START 1 - 1: Indicates the memory and step location of the current settings. Set: This is the parameter settings review screen 1.0s: The dwell timer is set to a test duration of 1 second. 1.24kVAC: The test voltage is set to 1,240 volts AC. 10.00mA: The high leakage current trip point is set to 10 milliamps.

  • Page 46: Operation

    B. SETUP PROCEDURE: 1. Memory configuration The model 4320/4520 is equipped with 6 memory programs numbered 1 through 6. Each memory location contains 6 separate steps that can be connected sequentially to the next consecutive step. Each step contains 4 separate locations, one for each function. Only one...
  • Page 47 OPERATION stored in the memory. The following memory map illustrates the separate location for each function. Memory 1 Step 1 Step 2 Step 3… Step 5 Step 6 Memory 2… 5 Step 1 Step 2 Step 3… Step 5 Step 6 Memory 6 Step 1 Step 2...
  • Page 48 EXIT key to store the current setting and return to the test mode, or press the SET key to advance to the next parameter. 4. To set the test type To change the Test type on the model 4320/4520, please press the SET key three times until the display shows:...
  • Page 49 OPERATION Mode Mode Mode Mode Press the Up (∧) or Down (∨) arrow keys to toggle the test selection between AC, DC, IR, and GND modes; then press the EXIT key to store the setting and return to the selected test mode or press the SET key if the parameters of the selected test desire to be changed.
  • Page 50 OPERATION 20.00mA AC and 5.00mA DC as the maximum setting for the 4320 and 100.00mA AC and 10.00mA DC as the maximum setting for the 4520. Both instruments include 0.00mA AC and DC as minimum setting. Any attempt to set the value outside this limits will produce two short beeps as an ERROR message.
  • Page 51 OPERATION Use the Up (∧) or Down (∨) arrow keys to enter the desired dwell time, then press the EXIT key to store the setting and return to the test mode or press the SET key to advance to the next parameter. If the dwell time is set to 0.0s, the instrument will operate in a continuous ON mode when the TEST button is depressed and released.
  • Page 52 OPERATION 6. IR insulation resistance test mode setting 6.1. To set the Output Voltage Please press the SET key until the display shows: Voltage = XXXXV Please use the Up (∧) or Down (∨) arrow keys to enter the desired test voltage, then press the EXIT key to store the setting and return to the test mode or press the SET key to advance to the next parameter.
  • Page 53 OPERATION 1000MΩ range of setting. Any attempt to set the value outside this limits will produce two short beeps as an ERROR message. A measured value below the Low Limit setting will result in a failure condition at the end of the Delay time setting. 6.4.
  • Page 54 OPERATION 7. GND Bond test mode setting 7.1. To set the Output Current Please press the SET key until the display shows: Current = XX.XA Please use the Up (∧) or Down (∨) arrow keys to enter the desired output current setting, then press the EXIT key to store the current setting and return to the test mode, or press the SET key to advance to the next parameter.
  • Page 55 OPERATION attempt to set the value more than 999.9s or less than 0.0s will produce two short beeps as an ERROR message. 7.4. To set the Offset Please press the SET key until the display shows: Ω Offset XXXm TEST to Auto Set Please use the Up (∧) or Down (∨) arrow keys to adjust the setting of the offset manually, then press the EXIT key to store the setting and return to the test mode, or press the SET key to advance to the next parameter.
  • Page 56 OPERATION advance to the next parameter. If Connect is set to ON the next step in the sequence will be executed. If Connect is set to OFF the test sequence will stop at this step. If step 6 is set to ON the test process will be connected to the first step of the next memory. Step 6 of the memory 6 does not have Connect ON/OFF option.
  • Page 57 Pressing the RESET button will silence the alarm and reset the instrument. 7.10. Key Lock or Memory Lock setting The model 4320/4520 is equipped with two different lockout selections. The first selection is Key Lock. Within this selection, you can lockout all front panel control functions except TEST and RESET.
  • Page 58 OPERATION Use the following chart to set the Key Lock and Memory Lock for your application. Key Lock Memory Lock Accessible keys TEST, RESET, and SET/Up-Down arrows for memory selection TEST and RESET To set the key Lock ON please press EXIT key once and then press the SET key until the display shows: Lock Use the Up (∧) or Down (∨) arrow keys to change the Lock setting to ON, then press the...
  • Page 59 OPERATION Memory Lock = OFF Memory Lock = ON Use the Up (∧) or Down (∨) arrow keys to change the Memory Lock setting, then press the EXIT key to store the setting and return to the test mode, or press the SET key to advance to the first system parameter (PLC Remote) again.
  • Page 60 OPERATION arrow key. To return to the previous test please press the Down arrow key and then EXIT key to return to the test mode. 1. AC or DC Dielectric Withstand Test Mode To initiate a test, press the TEST button on the front panel. The red High Voltage Arrow indicator will flash and the display will immediately show: X –...
  • Page 61 If a flash over occurs in the DUT during the test, which results in an OFL condition due to the current exceeds the maximum metering range, the red RESET button will illuminate and an alarm will activated. The 4320 display will show:...
  • Page 62 If the leakage current exceeds the metering range and neither a short circuit nor flash over occurred, the red RESET button will illuminate and an alarm will activated. The 4320 display will show: X –...
  • Page 63 OPERATION X – X Delay XXX.Xs Ω XXXXV IR XXXXM If the DUT has passed the test, the green TEST button will illuminate and a short audible beep tone will be activated. The display will show: X – X Pass XXX.Xs Ω...
  • Page 64 OPERATION X – X HI-Lmt XXX.Xs Ω XXXXV IR >1000M To stop the alarm, please press the RESET button once. The alarm will stop and the display will retain the failure information. The instrument is now ready for the next test. If the RESET button is pressed again, the failure information on the screen will be cleared and the display will indicate the setting data of the executed test.
  • Page 65 OPERATION X – X Dwell XXX.Xs Ω XX.XA GND XXXm If the DUT has passed the test, the green TEST button will illuminate and a short audible beep tone will be activated. The display will indicate: X – X Pass XXX.Xs Ω...
  • Page 66 OPERATION If the RESET button is pressed again, the failure information will be cleared and the display will indicate the setting data of the executed test. The display will show: X – X Set XXX.Xs Ω XX.XA GND XXXm If the resistance exceeds the high limit trip setting, but do not exceed the metering range, the red RESET button will illuminate and the alarm will be activated.
  • Page 67 When the EXIT key is pressed the instrument will continue with its normal failure indication process. The failure light and Alarm can be cleared by pressing the RESET button. If Output Error occurs please call the Slaughter Company Customer Support Center at 1-800-504-0055 for assistance.
  • Page 68 OPERATION D. CONNECTION OF REMOTE I/O: Two 9-pin “ D” type connectors are mounted on the rear panel that provides REMOTE- INPUT-OUTPUT control and information. These connectors mate with standard 9 pin D-sub-miniature connector provided by the user. The output mates to a male (plug) connector while the input mates to a female (receptacle) connector.
  • Page 69 2. SIGNAL INPUTS OF REMOTE I/O and PROGRAMMED TESTS The model 4320/4520 remote connector enables remote operation of the TEST, RESET, and REMOTE INTERLOCK functions, and allows the operator to select one of 6 preprogrammed tests.
  • Page 70 OPERATION PLC Remote ON A normally open momentary switch can also be wired across pins 2 and 5 to allow remote operation of the RESET function. For safety, the front panel RESET button remains active even when a remote reset switch is connected so that high voltage can be shut down from either location.
  • Page 71 The adapter box is an optional accessory and is not provided as standard equipment with the model 4320/4520. If you would like to acquire an adapter box for use with your instrument, please contact The Slaughter Company using the contact information provided in the Safety section of this manual.
  • Page 72 DUT to the chassis or dead metal of the product. With the model 4320/4520, you can perform the hipot and ground bond tests sequentially.

  • Page 73: Remote Bus Interface: Rs-232

    Remote BUS Interface: RS-232 This section provides information on the proper use and configuration of bus remote interface. The RS-232 remote interface is optional on all 4320/4520 models. Please see the OPTIONS section of the manual for details. RS-232 Interface This interface provides all of the control commands and parameter setting commands.
  • Page 74 Each command string should be terminated by the ASCII control code, New Line <NL>, or OAh. The following conventions are used to describe the commands syntax for the 4320/4520. Braces ({ }) enclose each parameter for a command string. Triangle brackets (< >) indicate that you must substitute a value for the enclosed parameter.
  • Page 75 REMOTE BUS INTERFACE: RS-232 File Editing Commands and Companion Queries The following commands are used to create or modify Test Setup Files. Command Description Value FL <file number> File Load file number = 1-6 SS <step number> Step Select step number = 1-6 Step Add ACW test Step Add DCW test Step Add IR test...
  • Page 76 REMOTE BUS INTERFACE: RS-232 Current HI-Limit LO-Limit Dwell Offset Frequency Connect (ON/OFF) Test Parameter Editing Commands These commands are used to modify the test parameter within each step. These commands require a parameter value to be included with the command. The companion query command will read the parameter.
  • Page 77 REMOTE BUS INTERFACE: RS-232 Command Name Test Value Types EH < value > Edit HI-Limit 4320: 0.0 – 20,000uA 4520: 0.0 – 99,990uA 4320: 0.0 – 5,000uA 4520: 0.0 – 10,000uA 0 - 1000MΩ 0 - 510mΩ EL < value > Edit LO-Limit 0.0 –...
  • Page 78 REMOTE BUS INTERFACE: RS-232 SML {1|0} System Memory Lock 1=On, 0=Off SML? Query Commands These query commands will retrieve data from the instrument. These commands include functions for retrieving test data, test results and remote hardware. Command Name Value List Testing Data Data from test in Process RD <...
  • Page 79 *ESR?, *ESE, *ESE? and *STB?. Command Name Description *IDN? Identification Query SLA, Model Number, Serial Number, Firmware Revision *RST Reset Command Resets 4320/4520 *TST? Self-Test Query 00H=OK 01H=TEST EEPROM ERROR *CLS Clear Status Command Clear Standard Event Status Register Clear Service Request Register *OPC...
  • Page 80 REMOTE BUS INTERFACE: RS-232 *PSC? Power-on Status Clear Query *ESR? Standard Event Status Register Query 0 - 255 *ESE <value> Standard Event Status Enable value = 0 - 255 Command *ESE? Standard Event Status Enable Query 0 - 255 *STB? Read Status Byte Query BIT 0, 01H,(1) Operation Complete BIT 1,02H,(2) Not Used...
  • Page 81 REMOTE BUS INTERFACE: RS-232 the Enable registers will be loaded with Enable register masks from non-volatile memory at power ON. *PSC? Queries the power-on status clear setting. Returns 0 or 1. *ESR? Queries the Standard Event register. Returns the decimal value of the binary-weighted sum of bits.

  • Page 82: Options

    OPTIONS MODEL 4320/4520 OPTIONS Introduction This section contains a list and descriptions of available factory installed options at the time of this printing. The list of options contains an option code number which can be referenced on the model option label on the rear panel of the unit when options are present.
  • Page 83 OPTIONS OPTIONAL REAR PANEL CONTROLS Description 01 Rear Outputs (4320) The Rear Outputs option gives the user the capability to access the High Voltage, Current and Return from the rear panel. The configuration and descriptions are as follows. 1. HIGH VOLTAGE OUTPUT JACK: For the connection of the detachable 6-foot (1.8 m) red high voltage test lead or three-prong receptacle adapter box.
  • Page 84 RS-232 interface. The 9-pin D-type subminiature connector labeled “ RS-232” is for connection of the 4320/4520 to any compatible PC. When selecting RS232, the protocol for interfacing and communicating with a PC can be...
  • Page 85 OPTIONS This page intentionally left blank.

  • Page 86: Section Ii Service Manual

    SECTION 2 SERVICE MANUAL...

  • Page 87: Calibration

    "Certificate of Calibration". It is recommended that you have this instrument recalibrated and a safety check done at least once per year. Slaughter recommends you use "Calibration Standards" that are NIST traceable, or traceable to agencies recognized by NIST to keep this instrument within published specifications.
  • Page 88 CALIBRATION To calibrate AC voltage please follow procedure on next paragraph, to calibrate other parameters use Up (∧) or Down (∨) arrow keys to scroll to the desired calibration point, then follow procedure on relative paragraph below. When the calibration process is completed successfully and the instrument accepts the entered calibration data it will output one short “...
  • Page 89 CALIBRATION Press the Up (∧) or Down (∨) arrow keys to enter the reading of the standard DC Voltmeter into the instrument. Then press SET key to store the voltage setting and to advance to the next calibration point or press the RESET button to return to the calibration menu without changing the calibration setting.
  • Page 90 CALIBRATION Current XX.XXmA Press the Up (∧) or Down (∨) arrow keys to enter the reading of the standard AC Milliammeter into the instrument. Then press SET key to store the current setting and to advance to the next calibration point or press the RESET button to return to the calibration menu without changing the calibration setting.
  • Page 91 CALIBRATION 7. To calibrate Insulation Resistance range Please connect a 100kΩ standard resistor across the HV and RETURN connectors. Press the Up (∧) or Down (∨) arrow keys until the display shows: Ω 6. IR 0.99M Ω Load = 100k Then press the TEST button on the front panel.
  • Page 92 CALIBRATION When previous calibration point was completed successfully display will show: Ω 8. IR 99.99M Ω Load = Please connect a 50MΩ standard resistor across the HV and RETURN connectors. Then press the TEST button on the front panel. The instrument will execute automatic calibration process.
  • Page 93 CALIBRATION 8. To calibrate Ground Bond test voltage Please connect a standard 6V AC Voltmeter across the CURRENT and RETURN connectors of the instrument. Press the Up (∧) or Down (∨) arrow keys until the display shows: 10. GND 6.00V Then press the TEST button on the front panel.
  • Page 94 CALIBRATION Press the Up (∧) or Down (∨) arrow keys to enter the reading of the standard AC Ammeter into the instrument. Then press SET key to store the current setting and to advance to the next calibration point or press the RESET button to return to the calibration menu without changing the calibration setting.

  • Page 95: Parts List

    99-10637-01¹ Amplifier Board 4520 HV4320A 99-10322-01 HV Control Board 4320 HV4320H 99-10638-01¹ HV Control Board 4520 RY4320 99-10323-01 HV AC/DC Switch Board 4320 RY4320 99-10641-01¹ HV AC/DC Switch Board 4520 CKB-06 99-10324-01 Keypad Board RS232-M1 99-10572-01 RS232 Interface Board 99-10573-01...
  • Page 96 PARTS LIST 99-10656-01¹ Fuse 15A, 250V Slow Blow 99-10297-01² Fuse Holder 20mm 99-10650-01¹ Fuse Holder 30mm 99-10355-01 LCD Display 16 x 2 Characters 99-10312-01² Power Switch 2P 15A 330-118-001¹ Power Switch 2P 250V 10A 330-113-001 Test Switch, Green 330-113-002 Reset Switch, Red 99-10333-01²...

  • Page 97: ¹ 4520 Only

    PARTS LIST Part Number Qty. Reference Description Designator 99-10671-01 Test/Pass Replacement Bulb 99-10672-01 Reset/Fail Replacement Bulb ¹ 4520 Only ² 4320 Only...

  • Page 98: Schematics

    SCHEMATICS Schematic Index Drawing Number Description Pages S04320² Wiring Diagram 4320 S04520¹ Wiring Diagram 4520 S99-10320 Main Control Board S99-10321 Amplifier Board 4320 S99-10637¹ Amplifier Board 4520 S99-10322 HV Control Board S99-10323² HV AC/DC Switch Board S99-10222 Keypad Board S99-10325...
