Axio LE card

General

Regulatory compliance FCC Class A, CE Mark Class A, ACA Class A,
Nominal card dimensions
Typical operating voltages and current
consumption (PCI Express card)
Voltage
Current
Total power consumption: 21.0 watts
Typical operating voltages and current
consumption (PCI-X card)
Voltage
Current
Total power consumption: 18.0 watts
PCI interface Full-size PCI Express x4 card,
or full-size PCI-X 66 MHz card
RoHS Directive 2002/95/EC
Video standards
NTSC, PAL, NTSC-EIAJ, 1080i/PsF, 720p
31 cm × 10.7 cm (12.2" × 4.2")
Card
Card including bracket
(13.875" × 4.9")
Overall thickness including components 1.9 cm
(0.75")
+3.3 V +5 V
2.2 A 1.5 A
+3.3 V +5 V
2.0 A 0.5 A
35.2 cm × 12.4 cm
+12 V
0.5A
+12 V –12 V
0.5 A 0.15 A
229
Axio LE card
