Monitoring audio levels for capture
If you select
time you configure your Matrox Axio capture settings or open the
to start a capture in Adobe Premiere Pro, VU meters will be displayed to let you
monitor the levels of your currently selected audio input source.
Clipping detectors
Peak level indicators
As you play your audio source, the color of the input level is green at or below
–12 dBSF, yellow between –12 and –6 dBFS, and red above –6 dBFS. The
clipping detectors will "light up" (become red) whenever audio clipping occurs.
The peak level indicators are thin lines that show the highest level recently
reached. These indicators will show the peak level for about two seconds or until
a higher peak level is reached.
If needed, adjust the audio level on your source device to keep the average input
level between –30 and –10 dBSF.
Chapter 7, Defining Your Adobe Premiere Pro Settings
Show VU meters
on the
Audio Capture Settings
page, each
Capture panel
