Supported main and secondary SDI output
formats on Matrox Axio LE
The following table lists the supported main and secondary SDI output formats
for Matrox Axio LE depending on your sequence's video format.
Sequence video
format
NTSC
PAL
486p @ 23.98 fps
486p @ 29.97 fps
576p @ 25 fps
720p @ 23.98 fps
720p @ 25 fps
720p @ 29.97 fps
720p @ 50 fps
720p @ 59.94 fps
1440 × 1080i @ 25 fps
1440 × 1080i @ 29.97 fps
1440 × 1080p @ 23.98 fps
1440 × 1080p @ 25 fps
1440 × 1080p @ 29.97 fps
1080i @ 25 fps
1080i @ 29.97 fps
1080p @ 23.98 fps
1080p @ 24 fps
1080p @ 25 fps
1080p @ 29.97 fps
¦ Note
your main or secondary SDI output. If you're working with an SD sequence or a
1080p @ 24 fps sequence, however, the analog output will be set to the same
format as the main SDI output.
Appendix B, Matrox Axio Workflows
Supported main SDI
output formats
NTSC
PAL
NTSC
NTSC
PAL
720p @ 59.94 fps
720p @ 50 fps
720p @ 59.94 fps
720p @ 50 fps
720p @ 59.94 fps
1080i @ 25 fps
1080i @ 29.97 fps
1080PsF @ 23.98 fps or 1080i
@ 29.97 fps
1080PsF @ 25 fps
1080PsF @ 29.97 fps
1080i @ 25 fps
1080i @ 29.97 fps
1080PsF @ 23.98 fps or
1080i @ 29.97 fps
1080PsF @ 24 fps
1080PsF @ 25 fps
1080PsF @ 29.97 fps
The analog outputs on Matrox Axio LE can be set to the same format as
Supported secondary
SDI output formats
NTSC
PAL
NTSC
NTSC
PAL
NTSC
PAL
NTSC
PAL
NTSC
PAL
NTSC
NTSC
PAL
NTSC
PAL
NTSC
NTSC
not supported
