Page 1: Power Supply
INSTALLATION & OPERATION MANUAL PWS1000R Rackmount Power Supply An ISO9001 and AS9100 Registered Company Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA) www.analyticsystems.com... - Page 2 Copyright (2005-2016) Analytic Systems Ware (1993) Ltd. Revised - May 20, 2016...
- Page 3 Improper connection can result in a risk of an electric shock. Analytic Systems does not recommend the use of the PWS1000R Series Power Supplies in life support applications where failure or malfunction of this product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effectiveness.
-
Page 4: Specifications
1.0 volts above or below the standard output voltage. An output overvoltage crowbar circuit protects devices connected to the converter. The PWS1000R Series Rack Mount Voltage Converter supplies either 12, 24 or 48 VDC from a 12, 24, or 48 VDC power source. - Page 5 Fastenings 18-8 Stainless Weight 12 lb / 5.5 kg * Specifications subjects to change without notice. Designed and manufactured by: ANALYTIC SYSTEMS WARE (1993) LTD. 8128 River Way p. 604.946.9981 f. 604.946.9983 Delta, BC V4G 1K5 Canada tf. 800.668.3884 US/Canada www.analyticsystems.com...
-
Page 6: Installation
Installation MOUNTING Mount the unit in a DRY location. Allow at least 4 inches of clearance around it for adequate cooling. POWER CONNECTION The unit is supplied with a 5 foot power cable. This should normally be adequate to connect to a source of power. -
Page 7: Operation
LOAD SHARE OPTION The units may be configured for load sharing if they are equipped with the optional output isolation diodes. To confirm that your unit has these diodes, use an ohmmeter to measure the resistance between one of the positive output terminals and one of the negative terminals. If the diodes are present the terminals will measure as not connected. -
Page 8: Output Adjustment
Output Adjustment The unit has an adjustment potentiometer to allow up to +/- 0.5V adjustment of the output voltage. This potentiometer is accessed through a small hole on the front plate of the voltage converter. As shipped from the factory, the unit is preset for a voltage of 13.6, 27.2, 36.3 or 54.4VDC. -
Page 9: Troubleshooting
Troubleshooting This unit provides LED indicators and a buzzer to help diagnose any problems. The unit should sound the buzzer to alert you prior to shutting itself down. You should immediately check the indicators to determine the cause of the shutdown. CHARGING Indicates that the battery charger is charging the batteries: If the LED is not on, the batteries may be fully charged and the charger is... - Page 10 Page intentionally left blank...
-
Page 11: Limited Warranty
