Hardware Overview
Front Panel
#
Item
1
Ethernet Port
2
Ethernet Activity
DC Power Input
3
DWM-312
1
2
Figure 1
This is a standard 10/100 Mbps Ethernet port to
connect any device via Cat 5/5e/6 RJ-45 cables.
Flashes green when there is Ethernet traffic.
5.5 mm barrel connector for power.
Table 1
3
Description
3
