3. Unit components

3.1.

Components

D
E
F
E
F
A
G
B
H
C
Fig. 11 – Tek Round model components
A
G
B
C
H
D
Fig.12 – Tek Basic and Tek Stone model components
I
Legend:
A– Door
B– Door handle
C– Front cover
D– Secondary air control
E – Primary air control
F– Fume baffle
G– Ash baffle
H – Air inlet
Legend:
A– Top cover in stone / metal
B– Door
C– Door handle
D– Front cover
E – Secondary air control
F– Primary air control
G– Fume baffle
H – Ash baffle
I– Air inlet
