Instruction Manual
English
Insert Fires
Models
Urano Eco 60 | Urano Eco 70 | Iaco
Eco 80 | Iaco Eco 90 | Siena Eco 60 |
Orion Eco 70 | Rialto Eco 80 | Rialto
Eco 90 | Back Box Eco | Back Box Slim
Eco
Read these instructions carefully before installing, using and servicing the unit. The
instruction manual is an integral part of the product.
Mod. 1040-A
