  • Page 1 Instruction Manual English TEK Free Standing Fires TEK Basic | TEK Stone | TEK Round TEK Unit | TEK Roll | TEK System TEK Corner | TEK Wall | TEK Lumber Mod. 527 – D...
  • Page 2 * • All local regulations, including but not limited to national and European standards, must be observed when installing, operating and servicing the unit; * SOLZAIMA free standing fire units are tested and found to be in compliance with the EN 13240:2002...

  • Page 3: Table Of Contents

    Energetic efficiency and performance ratings ................. 25 Using the unit for the first time ....................... 26 Normal usage ............................26 Forced ventilation Kit (It can only be applied on Tek Basic, Stone, Round and System) ......27 Safety ............................... 31 10. Cleaning and Maintenance ........................31 10.1.

  • Page 4: Solzaima

    This is why we have been manufacturing biomass units and heaters for the past 35 years. As a result of the persistence and unconditional support from a network of partners, Solzaima is currently the leading manufacturer of biomass heating units, especially with its range of central heating stoves with backboilers.
  • Page 5 Fig. 1 – Free standing fires: (A) Tek Basic, (B) Tek Stone, (C) Tek Round, (D) Tek Unit, (E) Tek Roll, (F) Tek System, (G) Tek Corner, (H) Tek Wall, (I) Tek Lumber...
  • Page 6 Fig. 2 – Dimensions of the Tek Basic model Fig. 3 – Dimensions of the Tek Stone model...
  • Page 7 Fig. 4 – Dimensions of the Tek Round model Fig. 5 – Dimensions of the Tek Unit model...
  • Page 8 Fig. 6 – Dimensions of the Tek Roll model Fig. 7 – Dimensions of the Tek System model...
  • Page 9 Fig. 8 – Dimensions of the Tek Corner model Fig. 9 – Dimensions of the Tek Wall model...
  • Page 10 Fig. 10 – Dimensions of the Tek Lumber model Features Basic Stone Round Unit Roll System Corner Wall Lumber Flue Ø (mm) Ø 150 Ø 150 Ø 150 Ø 150 Ø 150 Ø 150 Ø 150 Ø 150 Ø 150 Rated power (kW) 10,3 10,3...

  • Page 11: Unit Components

    A– Top cover in stone / metal B– Door C– Door handle D– Front cover E – Secondary air control F– Primary air control G– Fume baffle H – Ash baffle I– Air inlet Fig.12 – Tek Basic and Tek Stone model components...

  • Page 12: Optional Features

    To change the fume outlet initial vertical position to the horizontal position, please follow these steps: TEK Basic and TEK Stone models: Remove the top cover of the unit by sliding it horizontally and backwards to place the guide pins in their rearmost position. With the pins in this position, carefully lift and remove the top cover.
  • Page 13 Replace the fume baffle and top cover by following the steps above in reverse order; Use the additional cover provided (metal sheet for the Tek Basic model, and stone cover for the Tek Stone model) to cover the section left open on the top of the unit resulting from the repositioning of the fume outlet.
  • Page 14 TEK Round model: Release the external cover from the rear of the unit by unfastening the 4 screws. Next, lift up the cover, releasing it from the supporting props on the back of the unit; Remove the fume baffle (as described in section 9.2 under the "Cleaning and Maintenance"...
  • Page 15 Fig. 18 – Rear view of each model; (A) Section to remove for external air inlet Versions Tek Unit, Roll, System, Corner, Wall and Lumber For versions listed above, this system has to be purchased separately. For installation shall: 1 - Access the back of the computer and remove the back cover (A), in cases where it is applied; 2 - Place the outside air kit (C) in the oven, using the nuts supplied with the kit;...
  • Page 16 Version Tek Unit 1- Remove the cap installed on the stove (Fig 20 [A]), running diagonally and then raise it to release the clips of equipment; 2 Install the optional module separately purchased by the reverse order that the top cover is removed from the oven, with the same support points (Figure 20 [B]).
  • Page 17 Fig. 22 – Fixing System 2 Fig. 21 – Fixing System 1 System 3 (Figures 23, 24 and 25) 1- Placing the module (A) in the desired location and position the stove in the top of the same ensure that the side and the front of the stove are aligned with the side and the front of the module; 2- Using the screw (B), washer (C) and security support (D) included in the kit, connect the module to the stove through the existing hole in the top of the module and at the bottom of the stove;...
  • Page 18 Fig. 24 – holder System 3 Fig. 23 – Fixing System 3 Fig. 25 – Clamp the fastener placement the stove Version Tek Wall To proceed with the installation kit optional wall of this range must follow these steps: 1 - Remove the bracket (A) installed on the heater, unscrew the screws (B). Warning: When removing the screws, the stove no longer has the support (A) is the only foothold that the stove has the floor.
  • Page 19 Fig. 26 – Removing floor support Fig. 27 – Install wall bracket Fig. 28 – Positioning of the stove wall brackets...

  • Page 20: Installation

    4. Installation Warning: when installing this unit, be sure to follow all model-specific information, warnings, safety notices and local codes. 4.1. Combustion air and gas circulation This heating appliance must be installed in a well-ventilated area. Any required air inlet vents must be installed where not prone to becoming blocked;...
  • Page 21 sealing Fig.31- Correct Fig.32- Incorrect sealing * Ensure that the tube bindings do not strangle the tube (narrowing the flow), the inner tube walls are smooth and free of obstacles, and that the caps do not disturb the air circulation; Minimum distance equivalent to...

  • Page 22: Installation Space Requirements

    * If the chimney is made of brick, the flue should extend up to the very top, preferably in isolation. Otherwise, the fume temperature will drop, impairing air circulation. A suitable cap should be installed at the top of your chimney in accordance with its air circulation condition. Depending on atmospheric conditions, other types of chimney caps may be installed, such as the rooster cap.

  • Page 23: Instructions For Use

    5. Instructions for use 5.1. Fuel * Only firewood should be used in this type of appliance. The unit cannot be used as an incinerator, nor should other materials such as coal, painted wood, varnishes, thinners liquid fuels, glues or plastics be used as fuel.

  • Page 24: Power

    Table 2– Types of firewood that may be used in SOLZAIMA heat exchanger appliances, their geographical distribution and respective calorific value/reactions. Features Distribution Scientific Common name (total: 18 Notes Combustion name Smoke Heat Lighting Hardness districts) Speed Bragança, Castelo Branco,...

  • Page 25: Energetic Efficiency And Performance Ratings

    A Solzaima unit of 5kW with an efficiency rate of 75% is expected to consume approximately 1.6 kg (3.5 lbs) of firewood per hour to heat a 35 m (377 sq ft) room.

  • Page 26: Using The Unit For The First Time

    6. Using the unit for the first time * Ask the installation technician to turn on and start-up the unit to check its proper operation; * The first time the unit is used, the paint finish is cured by the heat, which may generate additional fumes.

  • Page 27: Forced Ventilation Kit (It Can Only Be Applied On Tek Basic, Stone, Round And System)

    8. Forced ventilation Kit (It can only be applied on Tek Basic, Stone, Round and System) * It is possible install a ventilation kit on some equipped with forced ventilation incorporate...
  • Page 28 Fig. 38 – Wiring Diagram * Remove front cover and introducing ventilation kit (figure 39-a) * Pass the electric cable through the hole and tighten the wire passes (figure 39-b)
  • Page 29 * Fix the ventilation kit (figure 39-c) * Before placing the front cover in place the Switch button (figure 39-d)
  • Page 30 Fig. 39 – Installation of ventilation kit Position I – Tangential fan automatically turns on with an air flow of 60m3/h when the thermostat reaches 50 °C. Position 0 – Tangential fan keeps inactive. Position II – Tangential fan is activated manually with an air flow of 165m3/h.

  • Page 31: Safety

    * In case of fire in the chimney, immediately close the door of the unit, as well as the primary and secondary air inlets; * We recommend that you use only spare parts supplied by the manufacturer – (SOLZAIMA). 10. Cleaning and Maintenance 10.1.

  • Page 32: Removing The Fume Baffle

    - Do not use detergent to clean the metallic parts of the unit. These should be cleaned using a dry cloth to remove any accumulated dust; - We recommend cleaning the chimney flue and its throat (located at the outlet of the unit) at least once a year.

  • Page 33: Troubleshooting

    12. End-of-life units * Around 90% of the materials used in the manufacture of these Solzaima units are recyclable, contributing towards a reduced environmental impact and a more sustainable planet; * End-of-life units should be taken to licensed waste operators. We advise contacting your local council to ensure their correct collection.
  • Page 34 * SOLZAIMA is a member of the Sociedade Ponto Verde, which manages waste packaging from products placed on the market by member companies; as such, the packaging that comes with your unit (i.e. plastic and cardboard) can be taken to your nearest recycling point.

  • Page 35: Glossary

    14. Glossary * cal (Calories): the amount of heat required to increase the temperature of one gramme of water by one degree centigrade. * cms(centimetres): unit of measurement. * CO (carbon monoxide): A lightly flammable, colourless, odourless gas that is very dangerous due to its high toxicity. * CO (carbon dioxide): Gas needed by plants for photosynthesis on the one hand, and emitted into the atmosphere on the other, contributing to the greenhouse effect.

  • Page 36: Warranty

    To exercise their rights, and provided that the deadlines specified in the preceding paragraph are not exceeded, the Buyer must report in writing to Solzaima, SA the lack of the Product conformity within a maximum of: 3.2.1 sixty (60) days from the date in which these have been detected, in the case of domestic use of the product;...
  • Page 37 Buyer, as well as all the charges resulting from the process. 3.14 Guarantee is valid for products and equipment sold by Solzaima SA only and exclusively within the geographical and territorial area of the country where the Product was sold by Solzaima.
  • Page 38 Circuit purge operations or unlocking of Circulator pumps are also excluded from warranty. 4.14. The installation of the product(s) supplied by Solzaima, SA must consider the possibility of its easy removal, as well as points of access to mechanical, hydraulic and electronic equipment and to the installation. When the installation does not allow immediate and secure access to the equipment, the additional costs of access and security measures will be Buyer responsibility.
  • Page 39 5. Inclusion of Warranty Solzaima, SA will fix at no charge to the Buyer, the defects covered by the warranty by repairing the product. Products or components replaced will become the property of Solzaima, SA. 6. Responsibility Solzaima, S.A. Without prejudice to legal provisions, the responsibility of Solzaima, SA, concerning warranty is limited to the established in these warranty conditions.

  • Page 40: Statement Of Performance

    16. Statement of Performance ECLARAÇÃO DE ESEMPENHO ECLARACIÓN RESTACIONES ECLARATION OF ERFORMANCE ÉCLARATION DE ERFORMANCE ICHIARAZIONE DELLE PRESTAZIONI DD-029 º Código de identificação único do produto-tipo | Código de identificación único del tipo de producto | Unique identification code of the product type | Le code d'identification unique du type de produit | Codice unico di identificazione del tipo di prodotto TEK B –...
  • Page 41 NB: 2456 Relatório de ensaio | Informe de la prueba | Test report | Rapport d’essai | Rapporto di prova K14202014T1 Desempenho declarado | Desempeño declarado | Declared performance | Performance déclarée | Dichiarazione di prestazione...
  • Page 42 Características essenciais | Desempenho | Desempeño | Performance Especificações técnicas harmonizadas Características esenciales | Essencial | Prestazione | Especificaciones técnicas characteristics | Caractéristiques armonizadas |Harmonized technical essentielles | Caratteristiche specifications | Spécifications essenziali techniques harmonisées | Specifiche tecniche armonizzate Segurança contra incêndio|Seguridad OK (A1).
  • Page 43 K14202014T1 4.2.4 (EN13240) A cada 10 m de conduta de fumos deve ser colocado um suporte de carga| cada 10 m de la salida de humos se debe colocar un soporte de carga|every 10 m of the flue should be placed a load support|tous les 10 m de conduit de fumée doit être placé...
  • Page 45 Please read this Instruction Manual carefully and keep it for future reference. All Solzaima products come with a 2-year warranty.
