MODELS COMBINATION

Emix Tank must be connected to an outdoor unit compatible with Emix.
For specifi c models see catalogue.(*)
(*) The models WITHOUT EMIX PORT can not support this new device for the production of domestic hot water.
This manual will use some models abbreviations of compatible outdoor units of the catalogue (Example G30 means
AEI1G30EMX-GR9FI30).
EG
The following diagram illustrates the concept exposed above and shows a system confi guration where three indoor direct
expansion units, a hydrokit for a fl oor system and an Emix Tank coexist, all connected to a G110.
HK
H O
2
Emix Tank always works in heating mode even when the heat pump is working for cooling of the environments; during
this operation mode, Emix Tank is able to recover the heat which would otherwise be lost in the outdoor air, signifi cantly
increasing the energy effi ciency of the entire system.
There are several possible confi gurations with Emix Tank and the one represented in the previous fi gure is just one of
many.
