Introduction
Congratulations on your purchase of the Extech SD800 CO
This meter measures, displays, and stores CO
stored on a SD card for transfer to a PC. This meter is shipped fully tested and calibrated and, with
proper use, will provide years of reliable service
Features
LCD simultaneously displays Carbon Dioxide, Temperature and Relative Humidity
Datalogger date/time stamps and stores readings on an SD card in Excel® format for easy
transfer to a PC
Selectable data sampling rate: 5, 10, 30, 60, 120, 300, 600 seconds

Product Description

1. Humidity/Temperature Sensor
2. Humidity Display
3. Temperature Display
4. CO2 Display
5. LOG (ENTER) button
6. SET button
7. AC adaptor socket
8. CO2 probe socket
9. ▲(TIME) button
10. ▼ button
11. Reset button
12. RS-232 output
13. SD memory card socket
14. CO probe
2
15. CO plug
2
Note: Battery Compartment and Tilt Stand are located on the back of the meter.
/Temperature/Humidity Datalogger.
2
, temperature and relative humidity readings. Data is
2
1
2
3
4
5
6
7
11
12
13
2
10
9
8
SD800-EU-EN- V2.4 1/13
